Safety Instructions; Installation - ViziT -M440C Manual

Colour monitor intended for use in video doorphones
Table of Contents

Advertisement

CAUTION
! The Monitor does not contain voltage above
Do not perform any connections or repair when the power is on.
Take care not to spill any liquids or chemically active substances on the product.
Unplug the power supply unit before cleaning the monitor. Clean by wiping with dry soft cloth. Do not use any liquid
cleaners, aerosol cleaners or abrasive agents.
Do not attempt to service the product by yourself. Please refer all services to qualified service personnel.
v
Colour 3 5
. " TFT LCD
v
Operation with two doorstations and extra camera (commutator BKM-440 required)
v
Operation with one doorstation, door bell button and extra camera (commutator BKM-440 not required)
v
Calls from doorstation and door bell button
v
Duplex intercom
v
Remote door unlocking with the
v
Door zone video monitoring
v
Activation of individual / storey doorstation by subscriber (duplex intercom and video monitoring)
v
5 ring tones, individual ring tone for each doorstation and door bell button.
v
3 ring volume levels
v
Individual image brightness and saturation for each doorstation and extra camera
v
LED indication of operating modes
Choose the position for monitor Recommended altitude is 150 cm from the floor to the monitor center
1
3
Make 3 holes
Refer to page 25 for Mounting Pattern.
Drive in concrete inserts
supplied with your monitor.
3

SAFETY INSTRUCTIONS

button
4
1
2
3
4
5
.
1
85
2
85
57
in the wall.
1
and screws
2
Figure
27V
.
FEATURES

INSTALLATION

Connecting terminals
1
Recess for cables
2
DC IN to connect power supply
3
6
unit SA03010029
Inlets for cables
4
Socket for handset jack
5
Fixing lugs
6
Figure
2 -
Rear view
2
3
Connect the wires to the terminals of
your monitor as shown in Fig. 4-7.
Match the monitor's fixing lugs with
the screws in the wall, and hook the
monitor on the screws.
Connect the handset
to the monitor.
3 -
Installation order
.
