Safety Instructions; Installation - ViziT -M456C Manual

CAUTION ! The Monitor does not contain voltage above
Do not perform any connections or repair when the power is on.
Take care not to spill any liquids or chemically active substances on the product.
Unplug the power supply unit before cleaning the monitor. Clean by wiping with dry soft cloth.
Do not use any liquid cleaners, aerosol cleaners or abrasive agents.
v
Colour 5 6 . " TFT LCD
v
Operation with two doorstations and extra camera (commutator BKM-440 required)
v
Operation with one doorstation, door bell button and extra camera (BKM-440 not required)
v
Calls from doorstation and door bell button
v
Duplex intercom
v
Remote door unlocking with the
v
Door zone video monitoring
v
Activation of individual / storey doorstation by Subscriber (intercom and video monitoring)
v
5 Ring tones
v
3 Ring volume levels
v
Individual ring tone for each doorstation and door bell button.
v
Individual image brightness and saturation for each doorstation and extra camera
v
LED indication of operating modes
4
5
8

SAFETY INSTRUCTIONS

button

INSTALLATION

1
2 3
6
7
Figure 2
27V .
FEATURES
Determine the position of the monitor.
Recommended altitude is 150 cm from the floor
to the monitor centre.
Make 3 holes in the wall,
3
depth = 30 mm.
Attach the monitor bracket
and fix securely with the screws
and concrete inserts
1
Plug the cable connector
Fix the monitor to the bracket with the screws
2.9x9.5 supplied.
7
Connect the handset
8
- Installation order
= 6 mm,
to the wall
4
3.5х25
2
supplied.
into the connector
5 6
to the monitor.
.
