H0T Series Dome Camera
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I
Camera
Type II
Camera
Type III
Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
DS-2CE56H0T-VPIT3ZE
DS-2CE56H0T-ITZE
DS-2CE5AH0T-VPIT3ZE
TURBO HD
User Manual
Model
0100001080320

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TURBO HD DS-2CE56H0T-VPIT3ZE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HIKVISION TURBO HD DS-2CE56H0T-VPIT3ZE

  • Page 1 TURBO HD H0T Series Dome Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model Type I DS-2CE56H0T-VPIT3ZE Camera Type II...
  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 4 Keep the camera away from liquid while in use for  non-water-proof device. While in delivery, the camera shall be packed in its  original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark Description DC Voltage AC Voltage...
  • Page 5: Product Features

    1 Introduction 1.1 Product Features The main features are as follows: High performance CMOS sensor  Low illumination, 0.01 Lux@(F1.2, AGC ON), 0 Lux  with IR IR cut filter with auto switch  OSD menu with configurable parameters  Auto white balance ...
  • Page 6: Installation

    1.2.3 Overview of Type III Camera Bubble Lens Back Box Video Cable Power Cord 12 VDC Figure 1-3 Overview of Type III Camera 2 Installation Before you start: Make sure that the device in the package is in good  condition and all the assembly parts are included.
  • Page 7 3. Loosen the screws on the bubble of the dome camera to remove the bubble and the black liner. 4. Attach the back box of type I camera/base plate of type II camera to the ceiling and secure them with supplied screws.
  • Page 8 2.1.2 Wall Mounting Before you start: You need to purchase a wall mounting bracket separately. Steps: 1. Drill 4 screw holes in the wall according to the holes of the bracket. 2. Attach the bracket to the wall by aligning the 4 screw holes of the bracket with expansion screws on the wall.
  • Page 9 3. Screw the bolts through the mounting bracket by aligning with the 2 bolt holes. Fit the toggles onto the bolts. 4. Push the two bolts through the two screw holes in the ceiling. Rotate the bolt till the toggle holds the ceiling tightly.
  • Page 10 Figure 2-10 Fix the Camera to the Base 5. Repeat the steps 7 to 9 of the 2.1 Ceiling Mounting section to complete the installation. 2.3 Ceiling Mounting of Type III Camera Before you start: Both wall mounting and ceiling mounting are suitable for the dome camera.
  • Page 11 For cement ceiling, expansion bolts are required to  fix the camera. For wooden ceiling, self-tapping screws are required. 5. Route the cables through the cable hole, or the side opening. 6. Connect the corresponding cables, such as power cord, and video cable. 7.
  • Page 12: Menu Description

    3 Menu Description Purpose: Call the menu by clicking the button on the PTZ Control interface, or call preset No.95. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. TVI DVR Camera Monitor Figure 3-1 Connection 2.
  • Page 13 3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDOE FORMAT You can set the video format as 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, and 2MP@30fps. 3.2 EXPOSURE Exposure describes the brightness-related parameters, which can be adjusted by EXPOSURE MODE, and AGC. EXPOSURE GLOBAL EXPOSURE MODE...
  • Page 14: Video Settings

    Figure 3-4 B & W  IR LIGHT You can turn on/off the IR LIGHT to meet the requirements of different circumstances.  SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure.
  • Page 15: White Balance

    CONTRAST, SHARPNESS, SARUTATION, DNR, and MIRROR are adjustable. VIDEO SETTINGS WHITE BALANCE BRIGHTNESS CONTRAST SHARPNESS SATURATION MIRROR BACK EXIT SAVE & EXIT Figure 3-6 VIDEO SETTINGS WHITE BALANCE White balance, the white rendition function of the camera, is to adjust the color temperature according to the environment.
  • Page 16: Factory Default

    DNR (Digital Noise Reduction) The DNR function can decrease the noise effect, especially when capturing moving images in poor light conditions and delivering more accurate and sharp image. You can set the DNR value from 1 to 9. MIRROR OFF, H, V, and HV are selectable for mirror. OFF: The mirror function is disabled.
