Summary of Contents for HIKVISION DS-2CE16H0T-IT3ZE

  • Page 1: User Manual

    This manual applies to the models below: Type Model DS-2CE16H0T-IT3ZE Type I Camera Type II Camera DS-2CE56H0T-IT3ZE This manual may contain technical incorrect places or printing errors, and the content is subject to change without notice.
  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 4: Installation

    Keep the camera away from liquid while in use for  non-water-proof device. While in delivery, the camera shall be packed in its  original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark Description DC Voltage AC Voltage 1 Introduction...
  • Page 5 Make sure that all the related equipment is power-off  during the installation. Check the specification of the products for the  installation environment. Check whether the power supply is matched with  your power output to avoid the damage. Make sure the wall is strong enough to withstand ...
  • Page 6 6. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the surveillance angle. Figure 2-3 3-axis Adjustment 1) Loosen the No.① adjusting screw to adjust the pan position [0° to 360°]. Tighten the No.① adjusting screw.
  • Page 7 Junction Box Body Screw Figure 2-5 Fix the Camera to the Ceiling 7. Route the cables through the cable hole, or the side opening of the junction box. 8. Combine the junction box cover with its body. Figure 2-6 Fix the Junction Box Cover back to its Body 9.
  • Page 8 Clip Plate Figure 2-8 Remove the Clip Plate 4. Fix the mounting base on the ceiling with supplied screws. Figure 2-9 Fix the Mounting Base on the Ceiling Note: The supplied screw package contains self-tapping  screws, and expansion bolts. For cement wall, expansion bolts are required to fix ...
  • Page 9 1). Hold the camera body and rotate the enclosure to adjust the pan position [0° to 360°]. 2). Move the camera body up and down to adjust the tilt position [0° to 75°]. 3). Rotate the camera body to adjust the rotation position [0°...
  • Page 10: Menu Description

    Figure 2-15 Fix the Junction Box 8. Repeat steps 5 to 9 of 2.2.1 Ceiling Mounting without Junction Box to complete the installation. 3 Menu Description Purpose: Call the menu by clicking the button on the PTZ Control interface, or call preset No.95. Steps: 1.
  • Page 11 1). Click up/down direction button to select the item. 2). Click Iris + to confirm the selection. 3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDOE FORMAT You can set the video format as 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, and 2MP@30fps.
  • Page 12 DAY/NIGHT B & W MODE IR LIGHT SMART IR  BACK  EXIT  SAVE & EXIT Figure 3-4 B & W  IR LIGHT You can turn on/off the IR LIGHT to meet the requirements of different circumstances.  SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from...
  • Page 13: Video Settings

    3.4 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SARUTATION, DNR, and MIRROR are adjustable. VIDEO SETTINGS  WHITE BALANCE BRIGHTNESS CONTRAST SHARPNESS SATURATION MIRROR  BACK  EXIT ...
  • Page 14: Factory Default

    SATURATION Adjust this feature to change the saturation of the color. The value ranges from 1 to 9. DNR (Digital Noise Reduction) The DNR function can decrease the noise effect, especially when capturing moving images in poor light conditions and delivering more accurate and sharp image.
