TURBO HD
H1T Series Dome Camera
User Manual
UD03908B
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
Model
DS-2CE56H1T-(A)VPIT3Z
DS-2CE56H1T-(A)ITZ
0100001061208

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION H1T Series

Summary of Contents for HIKVISION H1T Series

  • Page 1 TURBO HD H1T Series Dome Camera User Manual UD03908B User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model...

  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 4  Do not place the camera in extremely hot, cold, dusty or damp locations, and do not expose it to high electromagnetic radiation.  To avoid heat accumulation, good ventilation is required for operating environment.  Keep the camera away from liquid while in use. ...

  • Page 5: Product Features

    1 Introduction 1.1 Product Features The camera is applicable for both indoor and outdoor conditions, and the application scenarios include road, warehouse, underground parking lot, bar, etc.. The main features are as follows:  High performance CMOS sensor  Low illumination, 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR ...

  • Page 6: Ceiling Mounting

     Make sure that all the related equipment is power-off during the installation.  Check the specification of the products for the installation environment.  Check whether the power supply is matched with your power output to avoid the damage. ...

  • Page 7: Wall Mounting

    Note: In the supplied screw package, both self-tapping  screws and expansion bolts are contained. For cement ceiling, expansion bolts are required to  fix the camera. For wooden ceiling, self-tapping screws are required. 5. Route the cables through the cable hole, or the side opening.

  • Page 8: In-Ceiling Mounting

    Type I Camera Figure 2-5 Install Wall Mounting Bracket 4. Refer to step 3 of 2.1 Ceiling Mounting to remove dome camera’s bubble and the black liner. 5. Attach the back box/base plate of the dome camera to the wall mounting bracket and secure them with supplied screws.

  • Page 9: Menu Description

    Type I Camera Type II Camera Figure 2-8 Fix the Camera to the Mount 7. Connect the corresponding cables, such as power cord, and video cable. 8. Repeat steps 8 to 9 of the 2.1 Ceiling Mounting to complete the installation. 2.4 Mounting with Inclined Base of Type I Camera Steps: 1.

  • Page 10: Output Mode

    Steps: 1. Connect the camera with the TVI DVR, and the monitor shown as the Figure 3-1. 2. Power on the analog camera, TVI DVR, and the monitor to view the image on the monitor. 3. Click PTZ Control to enter the PTZ Control interface. 4.

  • Page 11: Smart Focus

    RESOLUTION Resolution refers to the number of the pixels can be displayed on the image. You can set the resolution as 5 megapixels or 4 megapixels. The higher the value, the finer the image is. FRAME RATE Frame rate refers to the number of image output in 1 second.

  • Page 12: Day & Night

    BRIGHTNESS Brightness refers to the brightness of the image. You can set the brightness value from 1 to 10 to darken or brighten the image. The higher the value is, the brighter the image is. D-WDR The digital wide dynamic range helps the camera provide clear images even under backlight circumstances.
  • Page 13 COLOR: the image is colored in day mode all the time. B/W: the image is black and white all the time, and the IR LED turns on in the low-light conditions. AUTO: The image switches from color to B/W or from B/W to color automatically according to the light condition.
  • Page 14 Figure 3-6 ADJUST SHARPNESS Sharpness determines the amount of detail an imaging system can reproduce. And you can adjust the sharpness from 0 to 15. The higher the value, the clearer and sharper the image appears. MONITOR GAMMA, BLUE GAIN, and RED GAIN are selectable. GAMMA is the name of a nonlinear operation used to code and decode luminance or tristimulus values in video or still image system，with USER, 0.45, 0.50, 0.55,...
