H0T Series Dome Camera
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II Camera
Type III Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
TURBO HD
User Manual
DS-2CE56H0T-(A)VPIT3ZF
DS-2CE56H0T-(A)ITZF
DS-2CE5AH0T-(A)VPIT3ZF
Model
0100001080109
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION DS-2CE56H0T-(A)VPIT3ZF
Summary of Contents for HIKVISION DS-2CE56H0T-(A)VPIT3ZF
-
Page 1: User Manual
This manual applies to the models below: Type Model Type I Camera DS-2CE56H0T-(A)VPIT3ZF DS-2CE56H0T-(A)ITZF Type II Camera DS-2CE5AH0T-(A)VPIT3ZF Type III Camera This manual may contain technical incorrect places or printing errors, and the content is subject to change without notice. -
Page 2: Regulatory Information
Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
-
Page 4: Product Features
Do not expose the device to high electromagnetic radiation or extremely hot, cold, dusty or damp environment. To avoid heat accumulation, good ventilation is required for the operating environment. Keep the camera away from liquid while in use for ... -
Page 5: Switch Button
Note: Press and hold the switch button for 5 seconds to switch the video output. Four kinds of video outputs are available: TVI, AHD, CVI, and CVBS. 1.2.3 Overview of Type III Camera Switch Button Back Box 12 VDC/24 VAC DC12V Power Cord Video Cable... - Page 6 Type I Camera Figure 2-1 The Drill Template 3. Loosen the screws on the bubble of the dome camera to remove the bubble and the black liner. 4. Attach the back box of type I camera/base plate of type II camera to the ceiling and secure them with supplied screws.
- Page 7 9. Fit the black liner back to the camera and tighten the screws on the bubble of the dome camera to finish the installation. 2.2 Wall Mounting of Type I and Type II Camera Before you start: You need to purchase a wall mount first. Steps: 1.
- Page 8 Figure 2-7 The Drill Template Note: Drill the cable hole (hole A) when adopting the ceiling outlet to route the cable. 3. Loosen the screws on the bubble of the dome camera to remove the bubble. Figure 2-8 Remove the Bubble and the Black Liner 4.
- Page 9 Figure 2-11 Fit the Black Liner Back 9. Tighten the screws on the bubble of the dome camera to finish the installation. Figure 2-12 Finish Installation 2.4 Wall Mounting of Type III Camera Before you start: You need to purchase a wall mount first. Steps: 1.
-
Page 10: Menu Description
3 Menu Description Purpose: Call the menu by clicking the button on the PTZ Control interface, or call preset No.95. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. TVI DVR Camera Monitor Figure 3-1 Connection 2. -
Page 11: Exposure Mode
3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDOE FORMAT You can set the video format as 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, and 2MP@30fps. 3.2 EXPOSURE Exposure describes the brightness-related parameters, which can be adjusted by EXPOSURE MODE, and AGC. Figure 3-3 EXPOSURE EXPOSURE MODE You can set the EXPOSURE MODE as GLOBAL, BLC, and... - Page 12 Figure 3-4 B & W IR LIGHT You can turn on/off the IR LIGHT to meet the requirements of different circumstances. SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure.
-
Page 13: Video Settings
3.4 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SATURATION, DNR, and MIRROR are adjustable. VIDEO SETTINGS WHITE BALANCE BRIGHTNESS CONTRAST SHARPNESS SATURATION MIRROR BACK EXIT SAVE & EXIT Figure 3-6 VIDEO SETTINGS WHITE BALANCE White balance, the white rendition function of the... -
Page 14: Factory Default
SATURATION Adjust this feature to change the saturation of the color. The value ranges from 1 to 9. DNR (Digital Noise Reduction) The DNR function can decrease the noise effect, especially when capturing moving images in poor light conditions and delivering more accurate and sharp image.
