H0T Series Bullet & Dome
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II Camera
Type III Camera
Type IV Camera
This manual may contain several technical incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.
TURBO HD
User Manual
Model
DS-2CE16H0T-ITF
DS-2CE16H0T-ITPF
DS-2CE16H0T-IT1F
DS-2CE16H0T-IT3F
DS-2CE16H0T-IT5F
DS-2CE56H0T-VPITF
DS-2CE56H0T-IRMMF
Camera
0100001080119
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION DS-2CE16H0T-ITPF
Summary of Contents for HIKVISION DS-2CE16H0T-ITPF
- Page 1 Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model DS-2CE16H0T-ITF Type I Camera DS-2CE16H0T-ITPF DS-2CE16H0T-IT1F Type II Camera DS-2CE16H0T-IT3F DS-2CE16H0T-IT5F Type III Camera DS-2CE56H0T-VPITF Type IV Camera...
-
Page 2: Regulatory Information
Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 4 Keep the camera away from liquid while in use for non-water-proof device. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark Description DC Voltage 1 Introduction 1.1 Product Features...
- Page 5 1.2.3 Overview of Type III Camera Video Cable Power Cord 12 VDC Mounting Base Switch Button Pan Adjusting Screw IR LED Tilt Adjusting Screw Black Liner Bubble Safty Rope Figure 1-3 Overview of Type III Camera Note: Press and hold the switch button for 5 seconds to switch the video output.
-
Page 6: Installation
2 Installation Before you start: Make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is power-off during the installation. Check the specification of the products for the ... - Page 7 6. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the camera according to the figure below to get an optimum angle. Figure 2-3 3-axis Adjustment 1). Loosen the P screw to adjust the pan position [0° to 360°].
- Page 8 5. Connect the corresponding power cord, and video cable. 6. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the surveillance angle. Figure 2-6 3-Axis Adjustment 1). Loosen the No.1 adjusting screw to adjust the rotation position [0°...
-
Page 9: Adjusting Screw
Figure 2-9 Fix the Mounting Base 5. Route the cables through the cable hole, or the side opening. 6. Connect the corresponding cables, such as power cord, and video cable. 7. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. - Page 10 Figure 2-12 Disassemble the Camera 2. Pry the snap joint anticlockwise to remove the bubble, and the black liner. Snap Joint Figure 2-13 Remove the Bubble 3. Attach the drill template (supplied) to the place where you want to install the camera, and then drill the screw holes, and the cable hole (optional) according to the drill template on the ceiling.
- Page 11 6. Connect the corresponding cables, such as power cord, and video cable. 7. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the camera according to the figure below to get an optimum angle.
-
Page 12: Menu Description
3 Menu Description Purpose: Call the menu by clicking button on the PTZ Control interface, or call preset No.95. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. TVI DVR Camera Monitor Figure 3-1 Connection 2. - Page 13 2). Click Iris + to confirm the selection. 3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDOE FORMAT You can set the video format as 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, and 2MP@30fps. 3.2 EXPOSURE Exposure describes the brightness-related parameters, which can be adjusted by EXPOSURE MODE, and AGC.
- Page 14 Figure 3-4 B & W IR LIGHT You can turn on/off the IR LIGHT to meet the requirements of different circumstances. SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure.
-
Page 15: Video Settings
3.4 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SARUTATION, DNR, and MIRROR are adjustable. VIDEO SETTINGS WHITE BALANCE BRIGHTNESS CONTRAST SHARPNESS SATURATION MIRROR BACK EXIT SAVE & EXIT Figure 3-6 VIDEO SETTINGS WHITE BALANCE White balance, the white rendition function of the... -
Page 16: Factory Default
DNR (Digital Noise Reduction) The DNR function can decrease the noise effect, especially when capturing moving images in poor light conditions and delivering more accurate and sharp image. You can set the DNR value from 1 to 9. MIRROR OFF, H, V, and HV are selectable for mirror. OFF: The mirror function is disabled.
