Billy Goat VQ VQ1002SP Owner's Manual

Billy Goat VQ VQ1002SP Owner's Manual

Billy goat vq vacuum cleaner
Hide thumbs Also See for VQ VQ1002SP:
Table of Contents

Advertisement

Quick Links

See also: Owner's/operator's Manual
Accessories
VACUUM HOSE
HOSE COUPLER
KIT
5" (127mm) x 8'
5" (127mm) For
(2.4m) For
coupling multiple
vacuuming in
hoses together to
hard-to-reach
increase
areas
vacuuming
distance.
P/N 830255
P/N 800334
Part No 830542
VQ Owner's Manual
BILLY GOAT VQ VACUUM
Owner's Manual
VQ902SPH, VQ1002SP
RIDE ON
KIT
CHARIOT KIT
Reduces operator
fatigue. Operator
stands while riding
behind vacuum.
Maximum load
300 lbs.(136 kg)
P/N 830257
Optional Debris bags
STANDARD
DEBRIS BAG
Standard on VQ
models. For
dusty
conditions.
P/N 830301
1
TURF
DEBRIS BAG
DEBRIS BAG
COVER
For use in
Directs dust
leaves and
downward
grass in non-
away from
dusty
operator.
conditions.
P/N
P/N 830284
830313
Form No F081409A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VQ VQ1002SP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billy Goat VQ VQ1002SP

Summary of Contents for Billy Goat VQ VQ1002SP

  • Page 1 BILLY GOAT VQ VACUUM Accessories VACUUM HOSE HOSE COUPLER 5" (127mm) x 8' 5" (127mm) For (2.4m) For coupling multiple vacuuming in hoses together to hard-to-reach increase areas vacuuming distance. P/N 830255 P/N 800334 Part No 830542 VQ Owner’s Manual...

  • Page 2: Table Of Contents

    ABOUT THIS MANUAL THANK YOU for purchasing a BILLY GOAT manufactured to provide years of reliable and productive service. This manual provides complete operating and maintenance instructions that will help to maintain your machine in top running order. Read this manual carefully before assembling, operating, or servicing your equipment.

  • Page 3: Serial Plate Data And Specifications

    SERIAL PLATE DATA Record the model number, serial number, date of purchase, and where purchased. Purchase Date: Purchased From: Specifications Engine: HP Engine: Type Engine: Fuel Capacity Engine: Oil Capacity Total Unit Weight: Overall Length Overall Width Overall Height Max. operating slope Sound at operators ear In accordance with 2000/14/EEC...

  • Page 4: General Safety

    This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. This symbol indicates important information that will prevent damage to your BILLY GOAT VQ Vacuum. This symbol indicates the engine oil level should be checked before operating this equipment.
  • Page 5 VQ Owner’s Manual DO NOT run this equipment indoors or in any poorly ventilated area. Refueling outdoors is recommended. DO NOT refuel this equipment while the engine is running. Allow engine to cool for at least two minutes before refueling. DO NOT store gasoline near an open flame.

  • Page 6: Vibration Data

    SOUND Sound tests were conducted in accordance with 2000/14/EEC, and were performed on 2-14-2002 under the conditions listed below. Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit for the sound power level for your model.

  • Page 7: Engine Labels

    INSTRUCTION LABELS The labels shown below were installed on your BILLY GOAT this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown.

  • Page 8: Packing Checklist & Assembly

    PACKING CHECKLIST Your Billy Goat is shipped from the factory in one carton, completely assembled except for the debris bag, deflector assy, upper handle assembly, rod nozzle door, and elbow assy. READ all safety instructions before assembling unit. TAKE CAUTION when removing the unit from the box the Handle Assembly is attached by...
  • Page 9 ASSEMBLY 1. UPPER HANDLE (item 41). Assemble securely to lower handle stubs (item 37) and handle brace (item 36), using screws (item 120 & 121), so that screw heads are on inside of handle. Otherwise, premature bag wear could result. 2.

  • Page 10: Operation

    OPERATION Like all mechanical tools, reasonable care must be used when operating machine. Inspect machine work area and machine before operating. Make sure that all operators of this equipment are trained in general machine use and safety. PUT OIL IN ENGINE BEFORE STARTING STARTING ENGINE: See engine manufacturer’s instructions for type and amount of oil and gasoline used.

  • Page 11: Debris Bag

    DEBRIS BAG Debris bags are normal replaceable wear items. Note: Frequently empty debris to prevent bag overloading with more weight than you can lift. An optional bag and dust cover is available for use where debris will be vacuumed in dusty conditions (See Optional Accessories shown on page 1.) DO NOT place bag on or near hot surface, such as engine.

  • Page 12: Maintenance

    MAINTENANCE ERIODIC AINTENANCE Periodic maintenance should be performed at the following intervals: Maintenance Operation Inspect for loose, worn or damaged parts. Clean Debris bag and check strap tightness Check Tire pressure Engine (See Engine Manual) Check for excessive vibration Check belt adjustment (pg. 15) Grease wheel zerks Lubricate Drive chain and oil control pivot points...
  • Page 13 DRIVE Chains and Belts are normal replaceable wear items. A new chain should not be used on worn sprockets. Sprockets should be replaced when replacing chains. MAINTENANCE Brake Adjustment: As parking brake wears, the brake discs may eventually require adjustment. To adjust belt, remove brake guard and tighten mounting nut that connects brake arm onto transmission.

  • Page 14: Warranty Claim Procedure

    Warranty Claim. • The distributor service manager will sign off on the claim and submit it to BILLY GOAT for consideration. • The Technical Service Department at BILLY GOAT will study the claim and may request parts to be returned for examination.

  • Page 15: Maintenance Record

    VQ Owner’s Manual MAINTENANCE RECORD Date Service Performed Part No 830542 Form No F081409A...

  • Page 16: Illustrated Parts & Parts Lists

    VQ Owner’s Manual PARTS DRAWING VQ Part No 830542 Form No F081409A...
  • Page 17 VQ Owner’s Manual Part No 830542 Form No F081409A...

  • Page 18: Parts List

    PARTS LIST ITEM ENGINE 10 HP INTEK B&S ENGINE 9 HP HONDA ANGLE MOUNT HDLE W A IMPELLER ASSY VQ (INCLUDES ITEM 4,5,6,7) KEY 0.25 SQ. X 2.75" W ASHER LOCK 7/16 TW ISTED TOOTH SCREW CAP 7/16 NF x 2 1/4 GR8 TORQ 55-60 FT LBS (75-81 N.m ) SPACER ENGINE W ASHER LOCK 5/16 TW ISTED TOOTH SCREW CAP 5/16 NF x 2 1/2 GRD.
  • Page 19 IT E M B R K T T R A N S M IS S IO N W A V Q B R K T T R A N S M IS S IO N R E A R W E LD LO N G B A R LIN K S H IF T O F F S E T V Q G U A R D D IF F E R E N T IA L V Q W E LD G U A R D C H A IN V Q W E LD...
  • Page 20 ITEM NUT REG. 5/16 NF WASHER SAE 1/4 WASHER SAE 5/16 WASHER SAE 3/8 WASHER FLAT CUT 1/4 WASHER FLAT CUT 5/16 WASHER 3/4 (0.765 x 1.25 x 0.06) BOLT SHOULDER 3/8 X 3/4" WASHER LOCK 1/4 WASHER LOCK 5/16 LABEL SPEED CONTROL SCREW MACH #10-24 x 2"...
