KV PUSH Owner's Manual
KV VACUUM Owner's Manual
ON BOARD
OPTIONAL
VACUUM
FELT/MESH
HOSE KIT
DEBRIS BAG
4" x 7.5'
For use in leaves
(102mm x
and grass in dusty
2.13m)
conditions.
For
vacuuming in
hard to reach
P/N 891126 FELT
areas.
BAG
P/N 891132
P/N 891125
MESH BAG
IMPORTANT- READ CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE.
Part No 891203
Image shown with optional accessories
KV601, KV650H, KV601FB, KV650HFB
Beginning Serial #: 102515001
Accessories
NOZZLE
CASTER KIT
WEAR
GUARD KIT
For use in
To allow for
increasing the
easy rolling and
life of your
maneuverability
nozzle by
on smooth
protecting it
surfaces.
from damage
P/N 891127
P/N 891128
Original Instructions
SHREDDER
KIT
Shreds
leaves,
reducing total
volume.
P/N 891153
1
KV LINER KIT
PROTECTIVE
COVER
Increases the
Protects the
life of the
machine from
housing by
the environment
protecting it from
when not in use.
damage.
P/N 891134
P/N 891137
891203_B_HI
