Summary of Contents for Billy Goat DL3701VEEU
- Page 1 792510...
-
Page 2: Specifications
792270 lever must engage switch for engine to start. Safety Decals The decals shown below were installed on your Billy Goat® DL Vacuum. If any decals are damaged or missing, replace them before operation. For your convenience in ordering replacement decals, part numbers are included below. ... -
Page 3: Packing Checklist
Boxing Parts Checklist Packing Checklist Your Billy Goat Debris Loader is shipped from the factory in one carton and requires some assembly. You must assemble the exhaust elbow, nozzle, handle loop for nozzle, hose booms, hose bands, hose coupler, and clamps using the related hardware included. -
Page 4: Initial Set-Up Assembly
21. Rotation Adapter Assist (P/N 792122) Initial Set-Up Assembly section for instructions on how to mount the elbow. 22. Knob (P/N 811230) 23. Bolt (P/N 8024069) CAUTION Assembly Elbow is heavy. Use caution when adjusting. Never stand directly under the elbow while adjusting direction of exhaust. Initial Set-Up Assembly Never direct exhaust into an area where bystanders may cross the path of the debris. ... -
Page 5: Maintenance Procedures
• Do not continue to crank your engine when the battery charge is low. Maintenance Procedures Unclogging a Clogged Hose With engine running and unit secured to a trailer, truck bed, or other similar surface, fully stretch hose in a straight line to dislodge the clog. -
Page 6: Charging The Battery
CAUTION Elbow is very heavy. Do not stand directly under elbow during removal. 5. Remove the ten (10) nuts and bolts that secure the liner to the housing. Use a 3/16" Allen wrench on the button- head bolts. Simultaneously use a 1/2" wrench on the nuts to loosen the hardware. ... -
Page 7: Periodic Maintenance
Periodic Maintenance Maintenance Operation Each Use Every 50 Hrs Every 100 Hrs Every 250 Hrs Every 300 Hrs Check engine oil Change engine oil Check air filter Clean air filter ... -
Page 8: Troubleshooting Table
Troubleshooting Table Problem Possible Cause Solution Will not vacuum or has poor vacuum performance • Nozzle is buried in debris • Withdraw the nozzle from the debris pile • Hose or exhaust is clogged • Unclog the hose or exhaust (See Maintenance section for more details) ... -
Page 9: Wiring Diagram
Wiring Diagram... - Page 10 Accessories Hose Replacement Kits Exhaust Hose Kits Trailer DL Standard on DL units. Long, clear polyurethane Extends the exhaust distance using either flexible Heavy duty spring axle trailer designed for towing hose. Available in 8", 10", 12", and 14" diameters. polyurethane or steel hose.
