Summary of Contents for Billy Goat DL3701VE
-
Page 2: Specifications
Hose must be installed over the switch and the switch Ratchet Strap 792270 lever must engage switch for engine to start. Safety Decals The decals shown below were installed on your Billy Goat® DL Vacuum. If any decals are damaged or missing, replace billygoat.com... -
Page 3: Packing Checklist
Packing Checklist Your Billy Goat Debris Loader is shipped from the factory in I.D. Item DL2901VE/ DL3701VE/ one carton and requires some assembly. You must assemble VEMM VEMM the exhaust elbow, nozzle, handle loop for nozzle, hose booms, hose bands, hose coupler, and clamps using the... - Page 4 Initial Set-Up Assembly Hardware I.D. Part Number 8171004 (3/8" FC 7/16" X 1" X 5/64") 791081 (2 3/8" x 2") 8041054 (3/8"-16 X 2") 8165003 ( 0.375"-16) 8024058 (0.375"-16 X 1.0") 8041058 (3/8"-16 X 3") Initial Set-Up Assembly 8160003 (3/8"-16) 791027 1.
-
Page 5: Operation
7. Securely attach exhaust elbow using the nuts and bolts (items N and M shown in Figure 3). 8. Install a standard 12 volt lawn and garden battery “U1” series (not included) with at least 240 cold cranking amps and a 40 amp hour rating by using battery bracket, hold down rods, washers and lock nuts. -
Page 6: Maintenance Procedures
that the hose will not wear on only one side, further increasing its life. CAUTION Keep the hose as straight as possible and avoid sharp bends Elbow is very heavy. Do not stand directly under elbow during operation for best pick-up and to avoid clogs. Never during removal. ... - Page 7 6. Remove impeller bolt and lock washer by using an impact 10. Tighten impeller bolt. Torque impeller bolt to 33-38 ft.lbs wrench. See Figure 9. (45-52 N.m) for DL9-18 series. Torque impeller bolt to 175-180 ft.lbs (237-244 N.m) for DL29-37 series. 11. Repeat steps 2 through 5 in reverse order. 12.
- Page 8 Periodic Maintenance Maintenance Operation Each Use Every 50 Hrs Every 100 Hrs Every 250 Hrs Every 300 Hrs Check engine oil Change engine oil Check air filter Clean air filter ...
-
Page 9: Wiring Diagram
Wiring Diagram... -
Page 10: Troubleshooting Table
Troubleshooting Table Problem Possible Cause Solution Will not vacuum or has poor vacuum performance • Nozzle is buried in debris • Withdraw the nozzle from the debris pile • Hose or exhaust is clogged • Unclog the hose or exhaust (See Maintenance section for more details) ... - Page 11 10" x 10' Hose P/N 791033 (DL1402SE, DL1402SEEU, DL1802V, DL1802VE, DL1802VEU, DL1802VEEU) 12" x 10' Hose P/N 791034 (DL2901VE/VEMM) 14" x 10' Hose P/N 792208 (DL3701VE) Hanging Extension Kit Swing Away Hitch Exhaust Extension Kit Allows the DL to hang from a vertical side panel Allows the DL to be attached to a hitch and swung Increases the height of the exhaust elbow. ...
