SOLO Basic Temperature Controller Introduction

General Description

AutomationDirect's SOLO Basic is a single loop temperature controller that can
control heating or cooling processes. Depending upon the particular model
of controller, the available outputs include relay, voltage pulse or current. On
select models there are two alarm outputs available with nine selectable alarm
types. SOLO Basic controllers have a single control output that can be used
for control of a heating or cooling application. Models with alarm outputs can
also be configured to use one of the alarm outputs as a second control output
allowing both heating and cooling control or two stage heating or two stage
cooling control. There are three types of control modes: PID, ON/OFF and
Manual. SOLO Basic can accept various types of thermocouple and RTDs.
Other features include:
• Auto Tuning (AT) function with PID control
• 1/16 DIN panel size
• 2 line x 4 character 7-segment LCD display for Process Value (PV): Red color, and Set
Point (SV): Green color
• Selectable display decimal point XXX.X or XXXX
• Selectable between °C and °F
• UL, CUL and CE agency approvals

Unpacking

After receiving the SOLO Basic Temperature Controller, please check for the
following:
• Make sure that the package includes the Controller, the mounting bracket and
hardware and the Quick Start Guide.
• Inspect the unit to insure it was not damaged during shipment.
• Make sure that the part number indicated on the serial number label corresponds
with the part number of your order.
Quick Start Guide
1st Ed. 02/19
SOLO Basic Temperature Controller User Manual
Chapter 1: Getting Started
Temperature Controller
Mounting Bracket
and Hardware
1–3
