Chapter 2: Installation and Wiring
Controller and Panel Cutout Dimensions
SLB4848 Series
SOLO
SLB
1
2
c
PV
A/M
SV
OUT1
OUT2
SET
Safety Information
Warning: To minimize the risk of potential safety problems, you should
follow all applicable local and national codes that regulate the installation
and operation of your equipment. These codes vary from area to area and it
is your responsibility to determine which codes should be followed, and to
verify that the equipment, installation, and operation are in compliance with
the latest revision of these codes
Warning: To prevent electric shock, do not touch the AC terminals while
power is supplied to the controller.
Warning: This controller is an open-type temperature controller. Make sure
to evaluate any dangerous application in which a serious human injury or
serious property damage may occur.
Wiring Notes: PLEASE READ PRIOR TO INSTALLATION.
Equipment damage or serious injury to personnel can result from the failure to follow
all applicable codes and standards. We do not guarantee the products described in
this publication are suitable for your particular application, nor do we assume any
responsibility for your product design, installation, or operation.
If you have any questions concerning the installation or operation of this equipment, or if
you need additional information, please call us at 1-800-633-0405 or 770-844-4200.
2–4
SOLO Basic Temperature Controller User Manual
Minimum Cutout and Spacing
