Chapter 2: Installation and Wiring
Terminal Identification
SLB4848 Series Wiring
SLB4848-R0
(No alarm output)
L
1
AC 100~240V
50/60 Hz 5VA
2
N
3 3
4
NO
5 5
OUT
COM
5A/250 Vac
6
SLB4848-C0
SLB4848-V0
(No alarm output)
L
1
AC 100~240V
50/60 Hz 5VA
2
N
3 3
4
+
5 5
OUT
6
–
2–6
SOLO Basic Temperature Controller User Manual
7
8
9
10
RTD
+
11
Tc
12
–
7
8
9
10
RTD
+
11
Tc
12
–
SLB4848-R2
(2 sets of alarm outputs)
L
1
AC 100~240V
3A
50/60 Hz 5VA
2
250 Vac
N
3 3
4
NO
5 5
OUT1
COM
5A/250 Vac
6
SLB4848-C2
SLB4848-V2
(2 sets of alarm outputs)
L
1
AC 100~240V
3A
50/60 Hz 5VA
2
250 Vac
N
3 3
4
+
5 5
OUT1
6
–
COM
7
8
ALM2
9
ALM1/OUT2
10
RTD
+
11
Tc
12
–
COM
7
8
ALM2
9
ALM1/OUT2
10
RTD
+
11
Tc
12
–
