The precision analog input replaces terminals 5 and 6 Analog input 1 in the
Precision
analog input
Drive. Terminals 5 and 6 can then not be used for any purpose. The
parameters associated with Analog input 1 now relate to the precision
input.
The serial communications interface allows the following:
Serial
• The Drive to be controlled and monitored remotely by a
comms.
interface
system controller
• The Drive to control or monitor another Drive
Installation
The UD78 must be fitted in the large option module bay of the Unidrive.
Precision analog input and serial communications connections are made by
9-way D-type connectors. The external Back-up
made by a pluggable 5-way screw-terminal block.
2
supply connections are
DC
UD78 User Guide
Issue code: 78nu2
