Installing the UD78

Before using the following procedure, refer to the
Warnings at the beginning of Chapter 2 Installing the Drive in
the Unidrive Installation Guide.
Warning
Before installing the UD78 in the Unidrive, ensure the
1
been disconnected from the Drive for at least 10 minutes.
Check that the exterior of the UD78 is not damaged, and that the
2
multi-way connector is free from dirt and debris. Do not install a
damaged or dirty UD78 in the Drive.
Remove the terminal cover from the Drive (for removal instructions,
3
see Installing the Drive and RFI filter in Chapter 2 of the Unidrive
Installation Guide).
Push the UD78 into the cavity immediately behind the keypad and
4
display until the UD78 locks in place.
Re-fit the terminal cover to the Drive.
5
Connect the
6
Set parameter .00 at
7
Check that parameter 7.31 is set at
8
fitted.
If the check in step 8 fails, perform the following:
9
• Remove the
• Wait at least 10 minutes.
• Remove the terminal cover.
• Check that the UD78 is fully inserted.
• Replace the terminal cover.
• Re-apply the
• Check again that parameter 7.31 is set at
6
supply to the Drive.
AC
to unlock security.
149
to indicate that the module is
1
supply from the Drive.
AC
supply.
AC
supply has
AC
.
1
