V-ZUG Unimatic TL WP Operating Instructions Manual
  1. Manuals
  2. Brands
  3. V-ZUG Manuals
  4. Dryer
  5. Unimatic TL WP
  6. Operating instructions manual

V-ZUG Unimatic TL WP Operating Instructions Manual

Hide thumbs Also See for Unimatic TL WP:
Table of Contents

Advertisement

Quick Links

Download this manual
Operating instructions
Unimatic TL WP
Tumble dryer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Unimatic TL WP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-ZUG Unimatic TL WP

Summary of Contents for V-ZUG Unimatic TL WP

  • Page 1 Operating instructions Unimatic TL WP Tumble dryer...
  • Page 2 Validity These operating instructions apply to: Model Type Product family Unimatic TL WP WT-UTL-WP Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2018...

  • Page 3: Table Of Contents

    Contents Restoring factory settings ........  18 Safety precautions  4 Care and maintenance  19 Symbols used............ 4 General safety precautions........ 4 Cleaning intervals ..........  19 Appliance-specific safety precautions .... 4 With message «A9» or «A11»......  20 Instructions for use.......... 6 Removing any fluff..........

  • Page 4: Safety Precautions

    Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that...
  • Page 5 1 Safety precautions ▪ This appliance is only suitable or pillows fitted with foam rub- for drying textiles which have ber pads should not be dried been washed in water. in the tumble dryer. ▪ The appliance is only to be ▪...

  • Page 6: Instructions For Use

    1 Safety precautions ▪ Do not operate the appliance without a Instructions for use door filter or with a damaged door filter. Before using for the first time Fluff can destroy the appliance! Caution: Burns hazard! ▪ The appliance must be installed and connected to the electricity supply in ▪...

  • Page 7: Using For The First Time

    Using for the first time Note The appliance can only be operated after standing in the normal operating posi- tion for about 2 hours. The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work.

  • Page 8: Where Is The Identification Plate

    3 Appliance description Where is the identification plate? 1 Identification plate with serial number (SN) Note down the serial number (SN) of your appliance on the back page of these operat- ing instructions. Appliance description Appliance overview The appliance operates with a closed air circuit. Moisture is extracted from the air with the help of a heat pump and then the air is reheated.

  • Page 9: Appliance Construction

    3 Appliance description Appliance construction The appliance door can be set to open to the left or to the right. Our Customer Services can make the necessary adjustments to the appliance. 1 Appliance door 5 Temperature sensor 2 Door filter with door filter mat 6 Evaporator 3 Operating and display elements 7 Front filter with front filter mat...

  • Page 10: Programme Overview

    4 Programme overview Additional functions Easy care End of programme Delayed start ▪ Door opener ▪ Drum illumination Display elements display (digital) for: ▪ Programme duration ▪ Delayed start ▪ Programme duration remaining ▪ Hints and trouble-shooting Level of dryness display ▪...

  • Page 11: Automatic Programmes

    4 Programme overview Crease guard The dried washing is moved at frequent intervals to prevent creasing. If the additional «Ultra care» function has been selected, «Crease guard» runs 90 minutes; with all other programmes it runs 30 minutes. «Crease guard» can be stopped at any time by opening the appliance door or by pressing the button.

  • Page 12: Additional Functions

    5 Drying Additional functions Easy care Gentle drying for mixed fabrics (e.g. shirts, pullovers and T-shirts). The level of dryness is reduced. Optimum load: 1–2.5 kg Delayed start Take advantage of cheap-rate electricity (setting range of up to 24 hours). During shut-off periods –...

  • Page 13: Selecting A Programme

    5 Drying Selecting a programme General note on programme selection Use the 'Programme overview' to determine which programme is the most suitable for your washing. Selecting a programme An automatic programme can be selected with the touch of a single button. All the ne- cessary settings for the programme are provided automatically.

  • Page 14: Selecting A Delayed Start

    5 Drying A new programme can be selected during this time. All additional functions selec- ted are cleared and must be reselected. – If no button is pressed within 15 seconds, the programme selected starts automat- ically. Selecting timed drying ▸ Close the appliance door. –...

  • Page 15: Interrupting A Programme

    5 Drying Interrupting a programme A running programme can be interrupted at any time to add or remove an item of wash- ing before time. After the appliance door is closed, the heat pump waits 10 minutes before starting again and the programme duration is correspondingly lengthened. ▸...

  • Page 16: End Of Programme

    6 User settings Aborting a programme through button selection With the appliance door closed, carry out the following step: ▸ Hold the active programme button – the indicator light illuminates – depressed and at the same time touch the button. –...

  • Page 17: Exiting User Settings

    6 User settings Exiting user settings ▸ Touch the button repeatedly until the display goes out. If no button is touched within the next 15 seconds, user settings is exited and the display goes out. Possible user settings The following diagram gives an overview of the possible user settings. Hold the button depressed for 5 seconds.

  • Page 18: Changing The Level Of Dryness

    6 User settings Changing the level of dryness The appliance is designed to provide the most energy-efficient drying. The moisture sensor continually monitors the level of dryness of the washing. If the washing is not be- ing dried sufficiently – or being overdried – the level of dryness can be reset. Changing the level of dryness alters the level of dryness setting of all the pro- grammes.

  • Page 19: Care And Maintenance

    7 Care and maintenance ▸ Touch the button repeatedly until appears in the digital display for no change. ▸ Touch the button. – appears in the digital display for restore factory settings. – The setting is taken over automatically and must not be confirmed. ▸...

  • Page 20: With Message "A9" Or "A11

    7 Care and maintenance Appliance Cleaning interval Cleaning part 4 Evaporator If dirty with ▸ Clean carefully using a vacuum cleaner with brush attachment. 5 Cooler filter As required with ▸ Remove any build-up of fluff while dry, then rinse under running water. Exterior of Occasionally ▸...

  • Page 21: Cleaning The Door Filter / Door Filter Mat

    7 Care and maintenance Cleaning the door filter / door filter mat Cleaning interval: Before change of user or with message «A9» / «A11» Do not operate the appliance without the door filter mat! Removing the door filter ▸ Open the filter cover 1. ▸...
  • Page 22 7 Care and maintenance For heavier deposits: ▸ Rinse the door filter 2 under running wa- ter. ▸ Clean with an abrasive liquid cleaning agent (immerse if necessary) and a sponge; use cleaning vinegar with hard water. ▸ Rinse off under running water and allow to drip dry.

  • Page 23: Cleaning The Front Filter / Front Filter Mat

    7 Care and maintenance Cleaning the front filter / front filter mat Cleaning interval: Before change of user or with message «A9» / «A11» Do not operate the appliance without the door filter mat! The appliance will not start without the front filter being in place. Removing the front filter ▸...

  • Page 24: Cleaning The Temperature Sensor

    7 Care and maintenance Inserting the front filter / front filter mat The appliance will not start without the front filter being in place. ▸ Centre the front filter mat 3 in the front fil- ter 1 so that the edges of the front filter mat are flush with the front filter.

  • Page 25: Cleaning The Evaporator

    7 Care and maintenance Cleaning the evaporator Cleaning interval: As required or with message «A9» / «A11» The appliance will not start without the front filter being in place. ▸ Take out the front filter 1. ▸ Clean the evaporator 2, behind the grille, carefully using a vacuum cleaner with brush attachment.

  • Page 26: Trouble-Shooting

    8 Trouble-shooting ▸ Wash on a 40 °C wash programme to clean off heavier deposits. Inserting the cooler filter The cooler filter does not have to be dry before being inserted in the filter case. ▸ Put the cooler filter 2 into the filter case 1.
  • Page 27 8 Trouble-shooting … A3 flashes in the display Possible cause Solution ▪ The vanes in the wash- ▸ Check and clean the drum vanes. A cleaning stone is ing drum are dirty or wet. particularly suitable for this..A9 flashes or A11 appears in the display Possible cause Solution ▪...
  • Page 28 8 Trouble-shooting ... in the display appears Possible cause Solution ▪ Front filter is not in place ▸ Insert the front filter correctly (see page 23). or is not in place cor- ▸ Acknowledge the message by touching the button. rectly: ▸...
  • Page 29 8 Trouble-shooting ... in the display flash alternately Possible cause Solution ▪ Overvoltage ▸ Acknowledge the message by touching the button. ▸ Switch the power supply off for about 1 minute. ▸ Turn the power supply back on again and select a pro- gramme.
  • Page 30 8 Trouble-shooting Possible cause Solution ▪ The demo mode (dEno) ▸ Unplug at the mains and then plug back in again. is switched on. appears: ▸ Open the appliance door. ▸ Press the buttons simultaneously. – The demo mode is switched off..

  • Page 31: Drying Tips

    9 Drying tips Drying tips Fabric care symbols To select the right drying programme, follow the fabric care symbols on garment labels. Tumble dry, medium heat Tumble dry, low heat Do not tumble dry General tips ▪ Use tumble dryer sheets sparingly. ▪...

  • Page 32: Spare Parts

    10 Spare parts Spare parts Please give serial number (SN) of the appliance and exact designation of the spare part when ordering parts. Door filter with door filter mat Door filter mat Front filter mat Cooler filter...

  • Page 33: Technical Data

    ▸ See identification plate 11.1 Product fiche In accordance with EU Regulation No. 392/2012 Brand V-ZUG Ltd The model identifier corresponds to the first alpha- numerics on the identification plate. Rated capacity for cotton laundry at full load Type of appliance...

  • Page 34: Consumption Values

    11 Technical data In accordance with EU Regulation No. 392/2012 Standard cotton programme Normal dry Weighted programme time mins. Programme time for the standard cotton pro- mins. gramme at full load Programme time for the standard cotton pro- mins. gramme at partial load Condensation efficiency class Condensation efficiency of the standard cotton pro- gramme at full load...

  • Page 35: Note For Testing Institutes

    12 Disposal 11.3 Note for testing institutes ▸ The declaration data can be determined correctly only after a run-in phase of 5 com- plete drying programmes with washing (automatic programme: Normal dry ▸ Wash the door filter each time after completing a drying programme. The moisture sensor of the appliance is calibrated based on average water hardness levels.
  • Page 36 12 Disposal 12.4 Note on heat pump This appliance is CFC-free. It contains fluorinated greenhouse gas covered by the Kyoto Protocol. Heat pump Hermetically closed Greenhouse gas R134a Filling quantity [kg] 0.490 GWP [(kg CO )/(kg greenhouse gas)] 1430 Total GWP [t CO 0.701...

  • Page 37: Index

    Index E42 ..............29 Easy care............12 A 0 ..............26 Electrical connection ........33 A 3 ..............27 End of the wash day ........16 A 9 ............... 20, 27 Energy-saving tips..........31 Cleaning the cooler filter ...... 25 Error messages..........26 Cleaning the door filter .......
  • Page 38 Model designation ..........2 Changing............ 16 Exiting ............ 17 Overview............ 17 Note for testing institutes........ 35 Validity..............2 Power consumption......... 34 Preparing the appliance ......... 12 Problems Washing Appliance not starting.........  29 Adding ............ 12 Damp laundry.......... 29 Unloading ............ 16 Programme duration at 0h01....

  • Page 39: Service & Support

    Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
  • Page 40 At the end of the wash day: ▸ Clean the door filter ▸ Close the appliance door 1030209-03 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
