Maytag MAT12PDSA Technical Information page 7

Component Testing Procedures
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.
CODE DISPLAY EXPLANATION
8.00 8. SPECIAL PRICING STOPPING HOUR
00 This is the selection of the hour using military time (24 hour clock) that the Special Pricing will "stop."
Adjustable from 0 to 23 by pressing the Permanent Press keypad.
Press Woolens keypad once to advance to next code.
9.10 9. SPECIAL PRICE DAYS
Represents the day of the week and if special pricing is to occur on that day of the week. The last
digit is "0" for OFF or "S" for ON.
Press the Delicates & Knits keypad once to select "0" and once for "S."
10
Press Permanent Press keypad to advance to next day of the week.
Press Woolens keypad once to advance to next code.
A.00 A. VAULT VIEWING
00 "OFF."
SC "ON." Press Delicates & Knits keypad once to select "SC." The money and/or cycle counter will be
viewable when the vault is opened. If "00" is selected, the service door will need to be opened to
activate, to view the money and/or cycle counter.
Press Woolens keypad once to advance to next code
b.05 b. VALUE OF COIN 1 (QUARTER DROP)
Represents the number of nickels given to the value of each coin in code 607 "regular cycle price" or
"special cycle price." For example: b.05 equals five nickels or one quarter. Press Permanent Press
05
keypad to advance from 1 to 99 in nickels.
Press Woolens keypad once to advance to next code.
C.20 C. VALUE OF COIN 2 (DOLLAR DROP)
Represents the number of nickels given to the value of each Dollar dropped in the dollar coin slot.
For example: C.20 equals twenty nickels or one dollar. Press Permanent Press keypad to advance
20
from 1 to 99 in nickels.
Press Woolens keypad once to advance to next code.
d.00 d. COIN SLIDE OPTION
00 "OFF"
CS "ON". Press Delicates & Knits keypad once to select "00" when coin drop is used, and "CS" for
models not using coin drops.
Press Woolens keypad once to advance to the next code.
E.00 E. ADD COINS OPTION
This option causes the customer display to show the number of coins (coin 1) to enter, rather than
the dollar and cents amount.
00 "OFF"
AC "ON". Press Delicates & Knits keypad 3 consecutive times for this selection.
Press Woolens keypad once to advance to the next code.
F.00 F. ENHANCED PRICING OPTION
00 "OFF"
CP Cycle Based Pricing-- Allows configuration of different prices for cold, warm and hot water cycles.
Su Super Cycle Pricing-- This allows customers to upgrade cycles by depositing extra money. Setup
codes "H" and "h" will only display when this option is turned "ON".
Press Delicates & Knits keypad 3 consecutive times for this selection.
Press Woolens keypad once to advance to the next code.
H.01 H. SUPER CYCLE UPGRADE PRICE (Skipped unless super cycle pricing is selected "F.Su".)
This represents the number of coin 1 required to upgrade a base cycle to super cycle. Advance
01 from 0-39 by pressing Permanent Press keypad.
Press Woolens keypad once to advance to the next code.
December 2003
!
WARNING
7
16022846 Rev 0
