Programming Procedures - Maytag MAT12PDSA Technical Information

Component Testing Procedures
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.

PROGRAMMING PROCEDURES

CODE DISPLAY EXPLANATION
607 6 REGULAR CYCLE PRICE
07 Represents the number of coins. See value of Coin 1 and Coin 2. Adjustable from 0-39 coins by
pressing the Permanent Press keypad. NOTE: PS MODELS ONLY- Represent the number of
push-in actuations of the coin slide.
Press Woolens keypad once to advance to next code.
710 7 WASH & AGITATION CYCLE
10 This is the number of minutes for Wash. Adjustable from 8-15 minutes by pressing the Permanent
Press keypad.
Press Woolens keypad once to advance to next code.
811 8 RINSE CYCLES
Represents the length and number of rinses (except "woolens" and "delicates"). The middle digit
is length of rinse agitation (1 to 4 minutes) and the last digit is number of rinses (1or 2). Advance
rinse option by pressing Permanent Press keypad.
Press Woolens keypad once to advance to next code.
900 9 CYCLE COUNTER OPTION
00 "OFF."
OC ON." Press Delicates & Knits keypad three consecutive times to select "OC" and three
consecutive times to turn "OFF" ("00"). Reset counter by going from "OC" to "00."
Press Woolens keypad once to advance to next code.
1.00 1. MONEY COUNTER OPTION
00 "OFF"
0C "ON". Press Delicates & Knits keypad three consecutive times to select "OC". Counter resets by
going from "OFF" to "ON".
C0 To select "On" and not turn off. First select "ON", then within two seconds press Delicates & Knits
twice, Permanent Press Once, and exit the setup mode.
2.00 2. SPECIAL PRICING OPTION.
00 "OFF."
SP "ON." Press Delicates & Knits keypad once to select "SP."
Steps "3." thru "9." codes are skipped if mode "2.00" is selected.
Press Woolens keypad once to advance to next code.
3.07 3. SPECIAL CYCLE PRICE
07 Represents the number of coins. Adjustable from 0 - 99 by pressing the Permanent Press
keypad.
Press Woolens keypad once to advance to next code.
5.00 5. MINUTES
00 This is the selection "MINUTES" of the time of day clock. Adjustable from 0 to 59 by pressing the
Permanent Press keypad.
Press Woolens keypad once to advance to next code.
6.00 6. HOUR
00 This is the selection "HOUR" of the time of day clock using military time (24 hour clock).
Adjustable from 0 to 23 by pressing the Permanent Press keypad.
Press Woolens keypad once to advance to next code.
7.00 7. SPECIAL PRICING STARTING HOUR
00 This is the selection of the hour using military time (24 hour clock) that the Special Pricing will
"begin ". Adjustable from 0 to 23 by pressing the Permanent Press keypad.
Press Woolens keypad once to advance to next code.
16022846 Rev 0
!
WARNING
6 December 2003
