1.1 Introduction

USM-110 is an ultra-compact digital signage player that delivers high-performance
graphics and supports H.265-encoded native 4K content at 60fps as well as dual Full
HD video output. The system's ultra-compact fanless design and support for diverse
mount options ensure easy installation in a wide range of application markets. More-
over, USM-110 is integrated with Advantech's Wise-Paas/ SignageCMS digital sig-
nage management software, which allows users to layout, schedule, and dispatch
signage contents to the USM-110 digital signage player over the Internet, enabling
remote delivery of diverse high-resolution multimedia.

1.2 Specification

1.2.1 General Specifications

System CPU
GPU
Graphics
Graphics Engine
Memory Capacity
Flash
Storage
Extension
Multimedia Display Resolution
HDMI
LAN
Serial Port
USB 2.0
I/O
OTG USB
Audio
Reset
LED Indicators
DC In
Micro SD Card
Expansion M.2
Mini PCIe
Dimensions
(L x W x H)
Mechanical
Weight
Power
Installation Mount Options
Operating System
Software
Software
USM-110 User Manual
USM-110
Arm® Cortex®-A17 quad-core processor (1.6 GHz)
Mali-T764
OpenGL ES 1.1/2.0/3.0, OpenCL 1.1, DirectX 11
2 GB onboard DDR3L (1333 MHz )
16 GB of onboard eMMC
Micro SD (up to 32 GB)
HDMI1: Native 4K resolution up to 3840 x 2160 (default
1080p)
HDMI2: 1920 x 1080
2
1 x 10/100/1000 Mbps)
1 (RS232/485/422 by
jumper)
4
1
1
1
1 x Power, 1 x Wireless
1
1
1 (for Wi-Fi module option)
1 (for 4G module option)
156 x 112 x 28 mm (6.14 x 4.41 x 1.10 in)
0.43 kg (0.94 lb)
12V/3A
VESA (75 x 75), wall, desktop, pole, magnet,DIN rail
Android 6.0
Wise-Paaas/SignageCMS Client
2
USM-110 Delight
8 GB of onboard eMMC
N/A
1
1 x 10/100/1000 Mbps
N/A
1
1
1
1
1 x Power, 1 x Wireless
1
1
1 (for Wi-Fi module option)
N/A
