Summary of Contents for d&b audiotechnik Ti10
- Page 1 Ti10 Manual 1.2 en...
- Page 2 General information Ti10 Manual Version: 1.2 en, 10/2018, D2602.EN .01 Copyright © 2018 by d&b audiotechnik GmbH; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.
-
Page 3: Table Of Contents
2.3 Operation..................6 2.3.1 Controller settings..............7 2.4 Dispersion characteristics............8 2.5 Technical specifications.............. 9 Ti10L Rigging procedure..........11 Manufacturer's declarations......... 12 4.1 EU conformity of loudspeakers (CE symbol)......12 4.1.1 WEEE Declaration (Disposal)..........12 d&b Ti10 Manual 1.2 en... -
Page 4: Safety Precautions
Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b Ti10 Manual 1.2 en... -
Page 5: Ti10 Loudspeaker
90° x 35° dispersion pattern (Ti10P). The Ti10 is a two way design, employing dual 6.5” drivers, a 1.4” exit compression driver and a passive crossover network. The low drivers are positioned in a dipolar arrangement providing an exceptional dispersion control towards low frequencies. -
Page 6: Connections
3. Fix the cover plate to the connector panel using the four countersunk screws. 2.3 Operation NOTICE! Only operate d&b loudspeakers with a correctly configured d&b amplifier, otherwise there is a risk of damaging the loudspeaker components. Applicable d&b amplifiers: 30D/10D/D80/D20/D12/D6. d&b Ti10 Manual 1.2 en... -
Page 7: Controller Settings
For acoustic adjustment the functions CUT, HFA, HFC and CPL can be selected. CUT mode Set to CUT, the low frequency level is reduced. The Ti10 is now configured for use with the Ti-SUB or other d&b active subwoofers. HFA mode (Ti10 PS setup only) In HFA mode (High Frequency Attenuation), the HF response of the system is rolled off. -
Page 8: Dispersion Characteristics
CPL setting. 2.4 Dispersion characteristics The graphs below show dispersion angle over frequency of a single Ti10 cabinet plotted using lines of equal sound pressure (isobars) at –6 dB and –12 dB. d&b Ti10 Manual 1.2 en... -
Page 9: Technical Specifications
Max. sound pressure (PS setup, 1 m, free field) 10D/D6 127 dB 30D/D80/D20/D12 130 dB (SPLmax peak, pink noise test signal with crest factor of 4) Ti10L frequency response line source, single cabinet, standard and CUT modes d&b Ti10 Manual 1.2 en... - Page 10 NL4 M: 1+/1– WR option: Brown: (+) / Blue: (–) Weight 11 kg (24 lb) / 10.5 kg (23 lb) Ti10P frequency response point source, standard and CUT modes Ti10 cabinet dimensions in mm [inch] d&b Ti10 Manual 1.2 en...
-
Page 11: Ti10L Rigging Procedure
"TI 385 d&b Line array design, d&b ArrayCalc" which is also provided with the T Flying frame. The d&b ArrayCalc simulation software can be downloaded from the d&b website at www.dbaudio.com. d&b Ti10 Manual 1.2 en... -
Page 12: Manufacturer's Declarations
Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b Ti10 Manual 1.2 en... - Page 14 www.dbaudio.com...
