- Page 1 Manual 1.1 en...
- Page 2 General information T10 Manual Version: 1.1 en, 02/2017, D2600.EN .01 Copyright © 2017 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this manual to the new owner.
-
Page 3: Table Of Contents
2.1. Product description..............5 2.2. Connections................6 2.3. Operation................6 2.3.1. Controller settings..............7 2.4. Dispersion characteristics............9 2.5. Technical specifications............10 Manufacturer's declarations........11 3.1. EU conformity of loudspeakers (CE symbol)....... 11 3.1.1. WEEE Declaration (Disposal)........... 11 d&b T10 Manual 1.1 en... -
Page 4: Safety Precautions
Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b T10 Manual 1.1 en... -
Page 5: T10 Loudspeaker
When used upright as a point source, the lens curves the wavefront of the line source providing a 90° x 35° dispersion pattern. The T10 is a two way design, employing dual 6.5” drivers, a 1.4” exit compression driver and a passive crossover network. The low drivers are positioned in a dipolar arrangement providing an exceptional dispersion control towards low frequencies. -
Page 6: Connections
"T10 Arc" and "T10 Line" setups These setups are selected when T10 loudspeakers are used as line sources. The selection depends on the curvature of the array. Both setups may be used within one array. The "Arc" setup is used for T10 loudspeakers when used in curved array sections. -
Page 7: Controller Settings
For acoustic adjustment the functions CUT, HFA, HFC and CPL can be selected. CUT mode Set to CUT, the low frequency level is reduced. The T10 is now configured for use with the T-SUB or other d&b active subwoofers. HFA mode (T10 PS setup only) In HFA mode (High Frequency Attenuation), the HF response of the system is rolled off. - Page 8 +5 dB) and can be set when the system is used in full range mode without subwoofers. Note: Make sure that all cabinets within the line array are Frequency response correction of the CPL function operated with the same CPL setting. d&b T10 Manual 1.1 en...
-
Page 9: Dispersion Characteristics
2.4. Dispersion characteristics The graphs below show dispersion angle over frequency of a single T10 cabinet plotted using lines of equal sound pressure (isobars) at –6 dB and –12 dB. Line source Isobar diagram T10 line source, horizontal Isobar diagram T10 line source, vertical... -
Page 10: Technical Specifications
D6/10D 127 dB D80/D20/D12/30D 130 dB (SPLmax peak, pink noise test signal with crest factor of 4) T10 frequency response line source, single cabinet, standard and CUT modes T10 loudspeaker Nominal impedance 16 ohms Power handling capacity (RMS/peak 10 ms) -
Page 11: Manufacturer's Declarations
Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b T10 Manual 1.1 en... - Page 12 www.dbaudio.com...
