7. Technical Data

line pressure :
max. operating temperature :
short-term load:
air connection (for hose) :
max. pneumatic air pressure :
min. pneumatic air pressure :
(Use dry and clean pneumatic air, only.)
shut-off valve
SWmini 41, 42
stroke
DN in mm
10 4
15 7
20 7
DN
10
15
20
closing pressure
in bar
8
8
6,5
kvs values in m
shut-off valve
2,7 m³/h
7,0 m³/h
9,0 m³/h
5 bar
135°C EPDM, HNBR
*FPM, *VMQ
140°C EPDM, HNBR
*FPM, *VMQ
*(no steam)
6x1mm standard
1/4" option
10 bar
6 bar
change-over valve
SWmini 43, 44
stroke closing pressure
in mm in bar
5 8
7 8
7 6,5
3
/h
change-over valve
2,5 m³/h
5,0 m³/h
3
7,5 m /h
