SPX 9500 Operating & Installation Instructions

SPX Corporation
5885 11th Street
Rockford, IL 61109-3699 USA
Internet Address:
http://www.powerteam.com
Tech. Services: (800) 477-8326
Fax: (800) 765-8326
Order Entry: (800) 541-1418
Fax: (800) 288-7031
MAX. WORKING
PRESSURE
MAX. FLOW
RATING
MAX. VALVE
CASE (RETURN
LINE) PRESSURE
PORT SIZES
NOTE:
● ● Inspect the valve upon arrival. The carrier, not the manufacturer, is responsible for any damage resulting
from shipment.
● ● Read and carefully follow these instructions. Most problems with new equipment are caused by improper
operation or installation.
WARNING
To help prevent personal injury:
● ● Before operating the pump, all hose connections must be tightened with the proper tools. Do not
overtighten. Connections should only be tightened securely and leak-free. Overtightening can cause
premature thread failure or high pressure fittings to split at pressures lower than their rated capacities.
● ● Should a hydraulic hose ever rupture, burst, or need to be disconnected, immediately shut off the pump
and shift the control valve twice to release all pressure. Never attempt to grasp a leaking pressurized hose
with your hands. The force of escaping hydraulic fluid could cause serious injury.
● ● Do not subject the hose to potential hazard such as fire, sharp surfaces, extreme heat or cold, or heavy
impact. Do not allow the hose to kink, twist, curl or bend so tightly that the oil flow within the hose is
blocked or reduced. Periodically inspect the hose for wear, because any of these conditions can damage
the hose.
● ● Do not use the hose to move attached equipment. Stress can damage the hose, resulting in possible
personal injury.
● ● Hose material and coupler seals must be compatible with the hydraulic fluid used. Hoses also must not
come in contact with corrosive materials such as creosote-impregnated objects and some paints. Consult
the manufacturer before painting a hose. Never paint the couplers. Hose deterioration due to corrosive
materials can result in personal injury.
Note: Shaded areas reflect last revision(s) made to this form.
© SPX Corporation
®
®
SPX Corporation
655 Eisenhower Drive
Owatonna, MN 55060-0995 USA
Phone: (507) 455-7000
Tech. Services: (800) 533-6127
Fax: (800) 955-8329
Order Entry: (507) 455-1480
Fax: (800) 283-8665
International Sales: (507) 455-7223
Fax: (507) 455-7746
2-POSITION/3-POSITION, 3-WAY/4-WAY MANUAL
CONTROL VALVE
Max. Capacity: 10,000 PSI
Specifications
10,000 PSI
5 GPM
500 PSI
3/8 NPTF

SAFETY PRECAUTIONS

Form No. 102527
Operating & Installation
Instructions for:
9500 9505
9501 9506
9502 9507
9504 9508
9504-PARK 9508-BOC
Sheet No.
Issue Date:
9509
9511
9520
1 of 1
Rev. 3-30-96
