Double seal change - over valve

Advertisement

Quick Links

Operating Manual
DELTA SDU4
Double Seal Change - Over Valve
Read and understand this manual prior to
operating or servicing this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APV DELTA SDU4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SPX APV DELTA SDU4

  • Page 1 Operating Manual DELTA SDU4 Double Seal Change - Over Valve Read and understand this manual prior to operating or servicing this product.
  • Page 5: Table Of Contents

    Table of Contents : Page : 1. General Terms 2. Safety Instructions 3. Mode of Operation 4. Auxiliary Equipment 5. Cleaning 6. Installation 6.1 Welding Instructions Dimensions / Weights 8. Technical Data 9. Maintenance Service Instructions 11-15 Installation of Seat Seal Trouble Shooting Spare Parts Lists Double Seal Change-Over Valves...
  • Page 7: General Terms

    General Terms This operating manual has to be read carefully and observed by the competent operating and maintenance personnel. We have to point out that we will not accept any liability for damage or malfunctions resulting from the non-compliance with this operating manual.
  • Page 8: Mode Of Operation

    Mode of Operation Double seal change-over valves DELTA SDU4 have been developed for the use in the brewing and beverage industries, in Control Unit dairy and food applications as well as for the chemical and Delta CU21N pharmaceutical industries. position The field of application of the DELTA SDU4 comprises the safe indicator shut-off and change-over of line sections.
  • Page 9: Auxiliary Equipment

    Auxiliary Equipment - Valve position indication A proximity switch holder for the valve position indication can be installed direct on the actuator. With SDU4 valves being equipped with valve position indication it must be observed that the max. closing pressure is reduced compared with the valve design being equipped with the control unit DELTA CU21N.
  • Page 10: Cleaning

    Cleaning For the cleaning of SDU4 valves distinction is made between two areas. - The flow chambers The passages of the valve are cleaned by the cleaning liquid during the cleaning of the connected pipelines. - The leakage chamber The cleaning of the leakage chamber is undertaken via the leakage valves.The cleaning liquid is supplied via one leakage valve and discharged to the atmosphere via the second leakage valve.
  • Page 11: Installation

    Installation Installation has to be done in such a way that fluids can drain off the valve housing and is preferably to be realized in vertical position. To provide for the dismantling of the valve insert, the valve housing ports of the upper and middle housing balls must be connected in a detachable manner by a flange or clamp connection.
  • Page 12: Dimensions / Weights

    Dimensions / Weights di m ensi ons i n m m st r oke i nst al l at i on w ei ght di m ensi ons i n K g i n m m SD U 4 54, 0 18, 0 66, 0 24, 0...
  • Page 13 8. Technical Data Product-wetted parts : 316 L, 1.4404 Other parts : 1.4301 Seals : Standard : EPDM Options : FPM, VMQ, HNBR Actuators : 1.4301 Max. operating temperature : 140° C EPDM 135° C VMQ, FPM, HNBR Sterilization temperature : 150°...
  • Page 14: Technical Data

    Technical Data Operating position: B / valve controlled Operating position: A / NC (normally closed) Note: The max. product pressure in case of compressed air failure as indicated in tab. 1 has to be considered for the design of the valves. Due to the seal technology, the max.
  • Page 15: Maintenance

    Maintenance - The maintenance intervals depend on the corresponding application and are to be determined by the operator himself carrying out temporary checks. - Required tools: - 1 x spanner SW13 - 1 x spanner SW17 - 1 x spanner SW19 - 1 x hexagon socket screw key 6 mm.
  • Page 16: Service Instructions

    10. Service Instructions Delta SDU 4 The item numbers refer to the corresponding spare parts lists DN: RN 01.054.64 / Tube: RN 01.054.064-1 Dismantling from the line system a. Shut off line pressure and discharge lines if possible. b. Remove the control unit (27) from the actuator (23). (Turn the ring in anticlockwise direction and remove the cover.) c.
  • Page 17 10. Service Instructions III. Actuator Spare parts list RN: 01.054.86 a. Remove the air hoses from the actuator. b. Take the inner hexagon screws out of the adapter (24) of the control unit. c. Screw off the two seal screws (1) by holding against the actuator by a strap wrench.
  • Page 18 Service Instructions Installation of seals and assembly of valve The item numbers refer to the corresponding spare parts lists RN: 01.054.65 DN / 01.054.64-1 Tube a. Slightly grease the housing seal (8) and insert it into the groove fig. for 10.V.a. of the yoke flange.
  • Page 19 Service Instructions Assembly of the valve a. Place the complete valve insert (actuator, yoke, upper valve shaft and upper valve housing) in the lower valve housing (1) and tighten it with the link clamp (5). Reconnect the valve housing with the line system. Reconnect the leakage valves.
  • Page 20 Service Instructions VIII. Proximity switch holder (valve design without control unit) If the valve is equipped with a proximity switch holder, the following proximity switch holder steps have to be observed during the dismantling of the valve: a. Remove pneumatic air lines. operating b.
  • Page 21: Installation Of Seat Seal

    Assembly tool for seat seal The assembly tool consists of: thrust piece ring with venting plug housing threaded bolt thrust piece Installation of the seat seal (item 15.1) in the upper valve shaft 1. Insert valve shaft into the housing in such a manner that ring the seal groove is in the valve housing.
  • Page 22: Trouble Shooting

    12. Trouble Shooting The item numbers refer to the respective spare parts drawings Valve is untight, leakages via the leakage valves Replace seat seals (15 / 15.1, 16). Check line pressure: perm. line pressure see 8. Leakages at the cylinder of the leakage valve Replace O-rings (5, 7, 8).
  • Page 24 Phone: +49(0) 23 03/ 108-0 Fax: +49(0) 23 03 / 108-210 For more information about our worldwide locations, approvals, certifications, and local representatives, please visit www.apv.com. Copyright © 2008 SPX Corporation The information contained in this document, including any specifications and other product details, are subject to change without notice.
