3.7 Modules with LEMO plugs

LEMO PIN
1
2
3
4
5
6
7 positive input for current measurement *
LEMO PIN
1
2
3
4
5
6
7 quarter bridge completion
LEMO PIN
1
2
3
4
5
6
7
* only with ISO2-8
** Special order BR2-4 with TEDS - then with 8-pin LEMO (because -SUPPLY is not GND and is also not TEDS-GND)
*** - Reference of +INDEX is -SUPPLY (GND)
- sensor supply voltage 5VDC/ 100mA (optional 300mA)
- other sensor supply voltages available via the optional sensor supply module
ISO2-8, C-8, OSC-16
+IN
-IN
+SUPPLY
-SUPPLY (GND)
TEDS (OneWire)
Pt100
current source
DCB2-8, B-8
+IN
-IN
+SUPPLY
-SUPPLY (GND)
TEDS (OneWire)
SENSE
quarter bridge completion /
HRENC-4 ***
+IN X
-IN X
+SUPPLY
-SUPPLY (GND)
+INDEX
+IN Y
-IN Y
imc CRONOSflex Getting Started Version 1.8 - 08.01.2014
UNI2-8
+IN
-IN
+SUPPLY
-SUPPLY (GND)
TEDS (OneWire)
SENSE/Pt100 current source
Sense for Pt100 3-wire
REMOTE plug
LV3-8, LV-16
+IN
-IN
+SUPPLY
-SUPPLY (GND)
TEDS (OneWire)
UNI-4 BR2-4 **
+IN
-IN
+SUPPLY +SUPPLY
-SUPPLY (GND) -SUPPLY
TEDS (OneWire)
-SENSE -SENSE
+SENSE_1/4B +SENSE
53
+IN
-IN
