52 Connection with connectors

3.5 DSUB-26 Pin configuration (High Density)

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13

3.6 REMOTE plug

Pin configuration of the LEMO plug (FGG.1B.306, 6-pin)
imc CRONOSflex Base Unit: CRFX-400, CRFX-2000 and the Power Handle: CRFX/HANDLE-POWER
CRFX/HANDLE-UPS-L and the CRFX/HANDLE-LI-IO-L:
Top view: Terminal connection
Signal
reserved
-IN1
SENSE1
-IN2
SENSE2
-IN3
SENSE3
-IN4
SENSE4
reserved
+IN1
1/4B1
+IN2
LEMO Signal
1
OFF
2
SWITCH
3
ON
LEMO Signal
1
ON / OFF
2
SWITCH1
3
ON / OFF
imc CRONOSflex Getting Started Version 1.8 - 08.01.2014
Pin
14
15
16
17
18
19
20
21
22
23
24
25
26
LEMO
4
SWITCH1
5
6 housing
LEMO
4
SWITCH
5
REFERENCE
6
Signal
1/4B2
+IN3
1/4B3
+IN4
1/4B4
+VB1
-VB1
+VB2
-VB2
+VB3
-VB3
+VB4
-VB4
Signal
n.c.
Signal
MUTE
