NOTE
"Move away from limit switch mode" will always work with hardware limit switches.
In the case of software limit switches, the mode will only work if a software limit
switch
(e.g. "10-Warning") was selected, the software limit switch will not trigger an error,
thus "Move away from limit switch mode" will not clear the software limit switch.
NOTE
"Move away from limit switch mode" must not be used when one of the following
error messages occurs:
•
•
•
If one of these errors has occurred, the wiring and parameter settings must be
checked first before resuming operation.
10/13
8
1144 with error stop was selected. If a setting with warning
Fault reaction
F1444 Pos. limit switch < Neg. limit switch
F1445 Both limit switches at the same time
F1446 Wrong limit switch wiring
CM-PROFINET
Status word
7 6 5 4 3 2 1

0 Bit

0 Ready to switch on
1 Switched on
2
Operation enabled
3 Fault
4
Voltage enabled
5 Quick stop (Low active)
6 Switch on disabled
7 Warning
8
-
9 Remote
10 Target reached
11
Internal limit active
12
-
13
-
14 -
15
Warning 2
