Figure 17. Remove the memory module

Remove the M.2 solid-state drive

Make sure the following FRUs (or CRUs) have been removed.
"Remove the lower case" on page 31
"Remove the battery pack" on page 32
Step 1. Remove 1 screw.
Figure 18. Remove 1 screw
Screw specifications
M2.0 x 3
Step 2. Remove the solid-state drive by pulling it away from the slot.
Number of screws
1
.
Chapter 4 Removing a FRU or CRU
39
