HANGZHOU WORLDE DIGITAL PIANO CO.,LTD
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD
WEBSITE: WWW.WORLDE.COM.CN
WEBSITE: WWW.WORLDE.COM.CN
WEBSITE: WWW.WORLDE.COM.CN
PANDA MIDI CONTROLLER
PANDA MIDI CONTROLLER
PANDA MIDI CONTROLLER
HANGZHOU WORLDE MUSIC ELECTRONIC
HANGZHOU WORLDE
HANGZHOU WORLDE MUSIC ELECTRONIC
EMAIL:SALES@WORLDE.COM.CN
EMAIL:SALES@WORLDE.COM.CN
EMAIL:SALES@WORLDE.COM.CN
USER'S MANUAL
USER'S MANUAL
C ELECTRONIC CO.LTD
ELECTRONIC CO., LTD
TEL:86 571 88730848
TEL:86 571 88730848
TEL:86 571 88730848
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Worlde PANDA
Summary of Contents for Worlde PANDA
- Page 1 HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN WEBSITE: WWW.WORLDE.COM.CN WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 TEL:86 571 88730848 TEL:86 571 88730848 PANDA MIDI CONTROLLER PANDA MIDI CONTROLLER PANDA MIDI CONTROLLER USER’S MANUAL...
-
Page 2: Table Of Contents
1.3Using The Panda With Your Software ........................6 1.4 MIDI Connections ................................ 6 1.5 Power Supply ................................7 Section 2:Basic MIDI Control From Your Panda ........................7 2. 1 Function Keys ................................7 2.1.1 Panda49 and 61 Functions ..........................7 2.1.2 Panda25 Functions ............................ - Page 3 HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 3.2.7 SNAP SHOT..............................17 3.3 Memory and data call back ............................18 3.3.1 MEMORY ................................. 18 3.3.2 RECALL ................................18 3.4 Control functions ................................ 18 3.4.1 SHIFT ................................
-
Page 4: Introduction
The eight fully assignable pads give you the ability to trigger samples. The eight fully assignable endless rotary encoders and sliders can be assigned as 135 controllers. The versatile and easy-to-use Panda keyboard is a great controller in the studio and live on stage. What’s in the Box? <... -
Page 5: Section1: Getting
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Section1: Getting 1.1 Panda Keyboards Overview 1.1.1 Top Panel Overview 1.1.2 Rear Panel Overview 1.1.3 Control Definitions The controls are referred by name throughout this manual. -
Page 6: Setup
1.2Setup If you intend to connect your Panda keyboard to a computer, please read sections 1.2 and 1.3 first. If you only intend to use your Panda keyboard to control a sound module or synthesizer using the external MIDI OUT you should skip to section 1.4. -
Page 7: Power Supply
TEL:86 571 88730848 1.5 Power Supply If you are using your Panda with a computer via its USB port, there is no need for an external power supply. Your Panda will draw its power from the computer. However, if you are intending to use your Panda without connecting to a computer’s USB port, then you will need to use an external power supply. -
Page 8: Panda25 Functions
Every time you press a key, a MIDI note message is sent with a velocity value between 0 and the maximum; this value specifies how hard you pressed the key. Since different people have different playing styles, your Panda offers 6 different velocity curves as shown below. -
Page 9: Octave
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN WEBSITE: WWW.WORLDE.COM.CN WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 TEL:86 571 88730848 TEL:86 571 88730848 To change the velocity curve: Press Velocity Curve button to start the button to start the selection function of velocity curve. -
Page 10: Channel
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN WEBSITE: WWW.WORLDE.COM.CN WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 TEL:86 571 88730848 TEL:86 571 88730848 (1)Press the SHIFT button for one or two times until the LCD displays Press the SHIFT button for one or two times until the LCD displays “Shift ON”. -
Page 11: Bank L/M
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN WEBSITE: WWW.WORLDE.COM.CN WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 TEL:86 571 88730848 TEL:86 571 88730848 button or +/-Button. The initial setting is 00 tton. -
Page 12: Programming The Controls On Your Panda
Examples of these controllable parameters include volume, pan, expression, reverb, chorus and portamento. Each of the controls on your Panda keyboard is able to send any of the 128 standard MIDI controller messages to control such parameters. Please note that in order for these effects to work, the MIDI device you are sending to must be able to receive these messages. -
Page 13: 3Assignable Slider
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 (5)Press the “Enter” button to confirm and the LCD will display “Done”. 2.5.3ASSIGNABLE SLIDER There’re 9 sliders that can be assigned controller No(49/61 only)independently. First press the “assign” button Then operate the slider, and the LCD shows the controller number and the controller value. -
Page 14: Groups: A,B,C,D,E(49/61)
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 (4)Press “Shift” button and the LCD will display “Pad Note”. (5)Press numeric button “3” and “4” and the LCD will display “34” on the bottom- left corner. -
Page 15: Split
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 3.1.2 SPLIT Keyboard Split ON/OFF function button. When Split is ON, the LCD displays the ’SPLIT_ON’., the keyboard is split to right section and left section by the split point, with each section use it’s own channel. The voice /channel of both channels is adjustable. -
Page 16: Other Controls
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 3.2 Other controls 3.2.1 MUTE MUTE ON/OFF function button. When MUTE function is ON, The LCD shows ‘MUTE ON’ no MIDI info will be sent. The operation steps and LCD displays the following: (1)Press the SHIFT button for one or two times until the LCD displays “Shift ON”. -
Page 17: Reset
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 3.2.4 GS Press CTRL ASSIGN and BANK L buttons at the same time(25)/GS ON button (49 and 61)to send GM ON message F0 41 10 42 12 40 00 7F 00 41 F7).LCD shows 'GS ON' when the message is sent. The LCD displays the following: 3.2.5 XG... -
Page 18: Memory And Data Call Back
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 3.3 Memory and data call back 3.3.1 MEMORY Press the MEMORY button. The system enters the storing state, it stores 6 groups setup value. Using the NUMERIC button1~6 to select the memory area. -
Page 19: Enter
3.5.1 Pressure Control Using the pressure control, the pads give you a different type of performance option on your Panda. You can control parameters on your software in a way that would not be possible on a standard dial or slider. The pressure pads can be used to make some very interesting effects. -
Page 20: Mmc(Midi Machine Control)
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Select the Backlit RGB Color of 8 Pads 3.5.4 Press “SHIFT” button and the LCD displays “SHIFT ON”, the knobs R1, R2 and R3 are used for RGB color. R1 is for red color. -
Page 21: Section 4: Usage Examples
In order to use the Panda with your sequencer, you need to set up the sequencer software so that the Panda is recognized as the sequencer’s MIDI input device. You need to choose a MIDI output device that is capable of making sound when MIDI data is sent to it. -
Page 22: Section 6: Troubleshooting
My Panda suddenly stopped working after having performed well since installation on a computer: <Switch off the unit and leave it off for 10 seconds. Then restart your computer, power up your Panda and try again. I have connected the Panda to my computer. When I press a key, there is a delay before I hear any sound. -
Page 23: Section 7: Technical Info
In such case, unplug the unit and plug it in again to restore normal operation. Note: Your WORLDE product has been tested to comply with FCC Standards FOR HOME OR OFFICE USE. Modifications not authorized by the manufacturer may void users authority to operate this device. -
Page 24: Section 8: Appendices
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Section 8: Appendices Appendix A ——MIDI IMPLEMENTATION CHART Function Transmitted Recognized Remarks Basic Default 1-16 Channel Changed 1-16 Mode Default Mode 3 Messages... -
Page 25: Appendix B - Useful Midi Data Tables
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Appendix B – Useful MIDI Data Tables BI-General MIDI Instruments-Program Change Numbers Piano Bass Reed Synth Effects 0 Acoustic Grand Piano 32 Acoustic Bass... - Page 26 HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 B2-Roland GS And Yamaha XG NRPN Messages NRPN NRPN Data Data CC99 CC98 CC06 CC38 08-00-7F (-64-0-+63) Vibrato Rate (relative change) 09 00-7F...
-
Page 27: Appendix C - General Midi Controller Numbers (Midi Cc's)
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 B5-General MIDI Drums-Note assignments MIDI Note Drum Sound MIDI Note Drum Sound MIDI Note Drum Sound Acoustic Bass Drum Chinese Cymbal Cabasa Bass Drum 1... -
Page 28: Appendix D - Assignable Controller Numbers To Linear Controllers
HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Appendix D – Assignable Controller Numbers to Linear Controllers This table applies to the following controls on your Panda: < Sliders < Aftertouch strip <Pitch bend wheel <Modulation wheel <Expression pedal... -
Page 29: Appendix F - Assignable Controller Numbers To Rotary Encoders
HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Appendix F – Assignable Controller Numbers to Rotary Encoders This table only applies to the Rotary encoders on your Panda 0-127 General controller PAD controller Pitch Bend Master Volume... -
Page 30: Appendix H - Factory Presets
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Appendix H - Factory Presets Penal controller Controller number Controller name Standard MIDI Controller Standard MIDI Controller Standard MIDI Controller Standard MIDI Controller... -
Page 31: Appendix I - Hexadecimal Conversion Chart
HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Appendix I - Hexadecimal Conversion Chart Hexadecimal value Decimal value Hexadecimal value Decimal value Hexadecimal value Decimal value... - Page 32 HANGZHOU WORLDE DIGITAL PIANO CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Sales Head Office: Hangzhou Worlde Music Electronic Co., Ltd Add:18Xianxing Rd, Xianlin Industrial Park, Yuhang District, Hangzhou, 311122,P.R.China Tel:0086 571 88730848 Fax:0086 571 88730748 Email:sales@worlde.com.cn...
