- Page 1 HANGZHOU BLUE WHALE MUSIC TECHNOLOGY CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Worlde Orca PAD64-A MIDI Controller User’s Manual - 1 -...
-
Page 2: Product List
Notice: To ensure your Orca PAD64-A can be used properly, please use both the USB cable and USB power cord for power supply. 1) Connect your Orca PAD64-A to your computer with both the USB cable and USB power cord if you are using it with a PC. - Page 3 To play your own user project in Ableton Live with ORCA PAD64 for LED feedback, you have to set the device and channel for Light track in your Ableton Live: 1) Select “WORLDE” for “MIDI TO”, 2)select CH.6 for Channels.
-
Page 4: Table Of Contents
4.1 Minimum System Requirements ............................13 4.2 To download the software editor of Orca pad64-A ......................13 4.3 Creating MIDI Presets with the Orca PAD64-A Software Editor ..................13 4.3.1 Overview: What is a Orca PAD64-A Preset? ........................13 4.3.2 Assign a couple of Pads to MIDI notes ..........................13 4.3.3 Assign a Pad to toggle a MIDI CC # between two values ....................14... -
Page 5: Introduction
TEL:86 571 88730848 1. Introduction Thank you for purchasing the Worlde Orca PAD64-A USB MIDI controller. To help you get the most out of your new instrument, please read this manual carefully. In order to use the functions of this product, you’ll need to make settings in the application you’re using. Make settings as described in the owner’s manual for your application. - Page 6 HANGZHOU BLUE WHALE MUSIC TECHNOLOGY CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 - 6 -...
-
Page 7: Parts And Their Functions
HANGZHOU BLUE WHALE MUSIC TECHNOLOGY CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 3. Parts and Their Functions 3.1 Orca PAD64-A Overview 3.1.1 Top Panel Overview 3.1.2 Rear Panel Overview - 7 -... -
Page 8: Parts And Their Functions
3.2.1 The pads Orca PAD64-A has 64 high quality velocity & pressure sensitive performance pads with RGB backlit which can be assigned easily as midi notes or MIDI CC buttons. The pads can be used to trigger drum hits to our software or hardware module. -
Page 9: Note Button
HANGZHOU BLUE WHALE MUSIC TECHNOLOGY CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 3.2.3 Note button The 64 pads have dual modes: trigger pads mode and key note mode. Click the note button to start the key note mode of the 64 pads, in this mode press +/-button to increase or decrease the current note by semitone. -
Page 10: Velocity Button
Every time you press a key, a MIDI note message is sent with a velocity value between 0 and the maximum; this value specifies how hard you pressed the key. Since different people have different playing styles, your Orca PAD64-A offers a number of different velocity curves. -
Page 11: Volume Button/Sound Selection Button
When the RGB backlight is blue for this button, it works as Master volume button. Click this button to set the master volume of Orca PAD64-A. It sends GM Master Volume message（F0 7F 7F 04 01 00 xx F7）. Press [Volume] button then press [<] or [>] button to control the volume of Orca PAD64-A. -
Page 12: And [>] Button
Connect the Orca PAD64-A to your computer with a USB cable via this port. 3.2.14. [MIDI OUT] Connector Use a five-pin MIDI cable to connect the MIDI OUT of the Orca PAD64-A to the MIDI IN of an external device. 3.2.15. [AUDIO OUTPUT] Connector Use a 3.5mm audio cable to connect the Audio Output of Orca PAD64-A to the external audio device. -
Page 13: Setup
4.3.2 Assign a couple of Pads to MIDI notes The natural thing to do when you’re starting a song is to lay down the kick and snare tracks. The Orca PAD64-A pads can be assigned to any MIDI note number that you like, so for this example we’ll set Pads 1 and 2 to trigger the General MIDI note numbers for the Bass drum and Snare drum (MIDI note numbers 36 and 38, respectively). -
Page 14: Assign A Pad To Toggle A Midi Cc # Between Two Values
One popular musical effect these days is to take an audio loop, filter it heavily for certain sections of a song, and switch it back to the full-open sound later in the song. You can pre-configure one of the Orca PAD64-A pads to send those commands to a filter plug-in that should be readily available in your DAW software. -
Page 15: Save The Changes To A Preset
The upper right-hand section of the MIDI Control Center software has a button called “Send to Keyboard”. Right below that is a pull-down menu that allows you to specify which of the Orca PAD64-A’s four memory locations will be the repository for the Preset you’ve created. -
Page 16: Recalling A Preset / Switching Between Presets
Memory button and press one of the 4 pads on the top left as shown in picture below. In the picture above the combination of the Memory button and Pad 2 will select Preset #2 from the Orca PAD64-A preset memory locations. - Page 17 HANGZHOU BLUE WHALE MUSIC TECHNOLOGY CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Reference RGB No. for some colors: COLOR WHITE BLACK GREEN BLUE CYAN MAGENTA YELLOW ORANGE - 17 -...
-
Page 18: Appendix
HANGZHOU BLUE WHALE MUSIC TECHNOLOGY CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 5.Appendix Appendix A- Toxic or Hazardous Substances and Elements Toxic or Hazardous Substances and Elements Part Number, Name and Description Cr(VI)) (PBB) (PBDE) ○... -
Page 19: Appendix B- Note Value And The Corresponding Numerical Number
HANGZHOU BLUE WHALE MUSIC TECHNOLOGY CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Appendix B- Note Value and The Corresponding Numerical Number Note Note Note NO. Note Note Note Note Note Bb 1 Eb 3... -
Page 20: Specifications
HANGZHOU BLUE WHALE MUSIC TECHNOLOGY CO.,LTD HANGZHOU WORLDE MUSIC ELECTRONIC CO., LTD WEBSITE: WWW.WORLDE.COM.CN EMAIL:SALES@WORLDE.COM.CN TEL:86 571 88730848 Bb 8 ●Specifications Connectors: USB connector Power supply: USB bus power mode Current consumption: 100 mA or less Dimensions (W x D x H): 256x256x36mm Weight : 840g Included items: USB cable, Owner’s manual...
