Operation

Main menu - Graphic - Select time

The diagram can be optimally designed. The increments for increasing and
reducing are programmed to obtain a resolution for this purpose.
The diagram is subdivided into 10 segments on the x-axis. The segment time and
the total displayed time can be set as follows:
Minimum segment time: 1 s
Maximum segment time: 12 h
The time values can be viewed as follows:
90
Increase segment time
Reduce segment time
Shift to later values
Shift to earlier values
