Use Chart to Determine
LANDSCAPE
Recommended Hole Pattern
A 100 mm x 100 mm
D 400 mm X 400 mm
B 200 mm X 200 mm
E 400 mm x 200 mm
C 300 mm X 300 mm
Screen
Screw Size
B ASPV32
M6 x 12
C P401
B ASPV40
M6 x 12
C P461
B E321
M6 x 12
D P521
A E324
M4 x 16
D P551
E E421
M6 x 12
C S401
E E461
M6 x 20
C S461
B LCD3210
M6 x 12
D S521
B LCD3215
M6 x 12
B SC40
E LCD4020
M6 x 12
B SC46
E LCD4215
M6 x 12
E V321
E LCD4615
M6 x 12
E V421
E LCD4620
M6 x 12
E V461
D LCD5220
M6 x 12
C X431BT
E LCD5710
M8 x 15
C X461HB
E M40
M6 x 12
C X461UN
E M46
M6 x 12

Installing Tilt Brackets

fi g 2.2
400 mm
300 mm
USE TILT BRACKET ONLY
WHEN MOUNTING TO
SCREEN USING 200 X 200
2
To prevent scratching the screen, set a cloth on a fl at, level surface that will support the weight of the screen. Place
screen face side down. If screen has knobs on the back, remove them to allow the tilt brackets to be attached. Place
tilt brackets (B and C) on back of screen as shown in fi g. 2.2. Note: Be sure to attach tilt brackets with handles fac-
ing outward as in fi gure 2.2. Align tilt brackets to screen mounting holes as recommended by chart below. Attach the
tilt brackets to the back of the screen using the appropriate combination of screws, either M4 x 16 socket pin screws
(N), M6 x 12 mm socket pin screw (G), M6 x 20 socket pin screw (H), or M8 x 15 mm socket pin screw (J) with multi-
washers (I) as shown in fi gures 2.3 and 2.4. Verify that all holes are properly aligned, and then tighten screws using
security allen wrench (F).
B
G, H,J,
or N
USING TILT
BRACKETS
ONLY
Orientation
and Screws
Recommended Hole Pattern
A
100 mm x 100 mm
B
200 mm X 200 mm
C
300 mm X 300 mm
Screen
Screw Size
Screen
M6 x 12
B
ASPV32
M6 x 12
B
ASPV40
M6 x 12
B
E321
M6 x 12
A
E324
M6 x 12
E
E421
M6 x 12
E
E461
M6 x 12
B
LCD3210 M6 x 12
M6 x 12
B
LCD3215 M6 x 12
M6 x 12
E
LCD4020 M6 x 12
M6 x 12
E
LCD4215 M6 x 12
M6 x 12
E
LCD4615 M6 x 12
M6 x 12
E
LCD4620 M6 x 12
M6 x 12
D
LCD5220 M6 x 12
M6 x 12
E
LCD5710 M8 x 15
M6 x 12
E
M40
E
M46
MAX Distance 400 mm
200 mm
HANDLES
FACE OUT
Landscape
*
Use multi-washers (I) to attach tilt
brackets (B and C) to your screen
when using M4 x 16 socket pin
screws (N), M6 x 12 mm socket
pin screw (G), or M6 x 20 mm
socket pin
screws (H)
M8 screws do not require
I*
C
multi-washers (I)
fi g 2.3
PORTRAIT
D
400 mm X 400 mm
E
200 mm x 400 mm
Screw Size
Screen
Screw Size
M6 x 12
C
P401
M6 x 12
M6 x 12
C
P461
M6 x 12
M6 x 12
D
P521
M6 x 12
M4 x 16
D
P551
M6 x 12
M6 x 12
C
S401
M6 x 12
M6 x 12
C
S461
M6 x 12
D
S521
M6 x 12
B
SC40
M6 x 12
B
SC46
M6 x 12
E
V321
M6 x 12
E
V421
M6 x 12
E
V461
M6 x 12
C
X431BT
M6 x 12
C
X461HB
M6 x 12
M6 x 12
C
X461UN
M6 x 12
M6 x 12
• Tighten screws so adapter brackets are fi rmly
attached. Do not tighten with excessive force.
Overtightening can cause stress damage to screws,
greatly reducing their holding power and possibly
causing screw heads to become detached. Tighten to
40 in. • lb (4.5 N.M.) maximum torque.
• If screws don't get three complete turns in the screen
inserts or if screws bottom out and bracket is still
not tightly secured, damage may occur to screen or
product may fail.
Portrait
fi g 2.4
6 of 7
Secure extension brackets (L) to left
tilt bracket (B) with four M5 x 6 mm
socket pin serrated washer head
screws (K).
Height of tilt brackets may be ad-
justed using holes above and below
center mounting location holes.
NOTE: Repeat using right tilt
bracket (C).
K
L
fi g 2.1
WARNING
USING
EXTENSION
BRACKETS
B
I*
C
G, H, J, or N
ISSUED: 03-26-10 SHEET #: 125-9106-6 12-11-14
B
CENTER
MOUNTING
LOCATIONS
