q. A djust the generator o u tp u t to produce a display as
close as possible to 5 divisions.
r. AD JU ST—The -MOO In p u t C capacitor fo r best fla t
top.
s. Repeat parts m through r u n til no fu rth e r im prove­
ment is noted.
t. Set the V E R T IC A L MODE switch to CH 2.
u. Repeat parts b through s fo r CH 2.
v. Disconnect the test setup.
11. Adjust Vertical Output Amplifier Compen­
sation (R357, C357, R367, R366, and C366)
a. Set:
V O L T S /D IV (both) 20 mV
A S E C /D IV 0.05 jus
b. Connect a 1-MHz, positive-going fast-rise square-wave
via a 5 0 -0 cable, a 10X attenuator, and a 5 0 -0 te rm in a tio n
to the CH 2 OR Y in put connector.
@
