Summary of Contents for Etac Cross 5
- Page 1 Etac Cross 5 Manual english 75190T 18-01-09 Etac Cross 5 Etac Cross 5 XL Etac Cross 5 Active...
-
Page 2: Table Of Contents
Head support ..............43 Adjusting rear seat height by changing rear wheel position 10. Technical data or rear wheel size ............15-16 Etac Cross 5, Etac Cross 5 XL ..........44 Rear seat height table ............17 Drum brake ..............18 11. Service and maintenance Upholstery ................45... -
Page 3: Intended Use
Etac Cross 5 and Etac Cross 5 XL are manual, cross-folded, allround wheelchairs with multiple functions and they are Etac Cross 5 and Etac Cross 5 XL have the best prerequisites intended for use both outdoors and indoors. Etac Cross 5 Active to create comfort, functionality and good manoeuvrability. -
Page 4: Description
Etac / Cross 5 / www.etac.com 2. Description 1. Push handles 12. Back support upholstery 2. Locking knob, push handles 13. Rear wheel 3. Back rail 14. Cross frame 4. Handrim 15. Seat upholstery 5. User brake 16. Leg support 6. -
Page 5: The Chairs Possibilities
3. The chair’s possibilities In the section ”The chair’s possibilities” you can see all the adaptions possible on the wheelchair. Variations may occur in different markets, e.g. as regards back support models. For more information, see www.etac.com or contact our customer service. - Page 6 Etac / Cross 5 / www.etac.com 3. The chair’s possibilities Seat depth Short frame 36-42 cm (triangular 36-49 cm) Seat depth Long frame 42-48 cm (triangular 42-55 cm) Standard Back support Height 30-45 cm mod. 2 Angle -5° - +15°...
- Page 7 Etac / Cross 5 / www.etac.com 3. The chair’s possibilities Normal knee angle Leg supports Narrow angle lockable, Narrow angle, short Elevating with foldable calf support from 40 cm seat width Leg supports Elevating with attachment and padded foldable Angle calf support.
-
Page 8: Accessories
Frame active Colour: black 01, white 92 4. Accessories Assembly instructions are always provided with accessories when they are supplied by Etac. Instructions are also available on our website, www.etac.com Settable = Adjusted using tools. Adjustable = Adjusted without tools. -
Page 9: 4. Accessories
Etac / Cross 5 / www.etac.com 4. Accessories Thigh support With soft cushion to extend handrims, brake and arm supports 5 mm on Widening kit each side Tray transparent, fits onto long arm support transparent, width 35-50 cm. Can be fitted onto short or Hemi tray long arm supports. - Page 10 Etac / Cross 5 / www.etac.com 4. Accessories fits onto the existing foot support, from seat width 40- Extended foot support 55 cm two pieces, with snap-lock, fixing points on the wheel- Positioning belt chair frame Seat belt with snap lock Adjustable in height, depth and angle.
-
Page 11: 4. Accessories
Etac / Cross 5 / www.etac.com 4. Accessories Trunk support Cross back 3A, swing-aside, medium or large cushion telescopic, foldable, settable height, adjustable length Anti-tips and angle (not with foldable arm supports) Anti-tips For Etac Cross 5 Active two parts, one of which is an elasticated section that is... -
Page 12: Settings
Etac / Cross 5 / www.etac.com 5. Settings Front seat height The front seat height may be adjusted by: - Using the front fork attachment, adjustable in height and angle. -Changing the position of the castor wheel. -Changing the front fork. -
Page 13: Adjusting The Front Seat Height By Changing The Castor Wheel/Front Fork
** Possible in balance position 4-6 with 3° backward inclination and Std leg support. Make sure the fork/castor wheel can rotate freely without hitting the wheelchair or user. For 8x2” castor wheels, use the Transit fork (gives a seat height of 47-51 cm). *** With Cross 5 XL max user weight 135 kg. -
Page 14: Mounting The Front Fork
Etac / Cross 5 / www.etac.com 5. Settings Mounting front fork - Pull out the cover plug (A) and unscrew the retain- ing nut (B). Pull out the front fork and put the be- velled washer (C) and the bearing on the new fork. -
Page 15: Rear Seat Height
Etac / Cross 5 / www.etac.com 5. Settings Rear seat height Rear seat height can be adjusted by: -Changing the position of the rear wheel in the frame. -Changing the position of the rear wheel in the camber washer. -Changing the rear wheel. - Page 16 Etac / Cross 5 / www.etac.com 5. Settings When assembling, check so that the rear wheel axle is correctly adjusted. The button in the hub must pop out to the original position. Assembly in pos. G1 & G2 24 mm 17 mm Assembly 0°...
-
Page 17: Rear Seat Height Table
Etac / Cross 5 / www.etac.com 5. Settings Rear seat height table Rear wheel position, height Wheel Seat hgt Distance 20” 46 cm 4,5 cm 22” 48,5 cm 7,0 cm 24” 51 cm 9,5 cm 26” 53 cm 12 cm 20”... -
Page 18: Drum Brake
Etac / Cross 5 / www.etac.com 5. Settings Drum brake E1 E2 E3 E4 E5 E6 E6 E5 E4 E3 E2 E1 D1 D2 D3 D4 D5 D6 D6 D5 D4 D3 D2 D1 C1 C2 C3 C4 C5 C6... -
Page 19: User Manual
Etac / Cross 5 / www.etac.com User manual 75190T 18-01-09 This part of the manual (User manual) should be torn out and at all times follow the wheelchair. This as it contains impor- tant user information. Etac Cross 5 Etac Cross 5 XL... -
Page 20: Symbols And Warnings
Etac / Cross 5 / www.etac.com User manual Contents User manual Symbols and warnings .............20 Transportation in vehicles ..........21 Handling ..............22-23 Settings seat comfort Back support cover ............24 Seat cushion ..............24 Back support upholstery ..........24 Back support angle ............24 Foot supports ...............25... -
Page 21: Transportation In Vehicles
Cross brace or head support attachment 3A must be or around the back tubes. used (Cross 5) • Cross brace must be used (Cross 5 XL). • Rear wheels must have handrims. 3) According to directive 2001/85/EC, appendix VII, point •... -
Page 22: Handling
Etac / Cross 5 / www.etac.com User manual Handling Unfolding • Push down on one side of the seat frame, using the whole of the flat of the hand. • Do not hold the seat frame tube while unfolding as there is a risk of pinching your fingers. - Page 23 Etac / Cross 5 / www.etac.com User manual Leg support For lifting a wheelchair without lockable leg supports: Swing in the leg supports under the The leg supports can be removed/swung to the side if seat, or remove them, and lift using the frame needed.
-
Page 24: Settings Seat Comfort
Etac / Cross 5 / www.etac.com User manual Settings seat comfort Seat comfort qualities. The back support setting is a combination of angles, Good seating comfort depends on the needs and possi- height and shape. This is why the angle settings and bilities available to each individual. -
Page 25: Foot Supports
Etac / Cross 5 / www.etac.com User manual Settings seat comfort Foot supports Never stand on the foot supports as there is a risk of Adjust the height until you are sure that your feet are tipping! supported and your thighs are resting on the cushion. -
Page 26: Driving Technique, Maneuvering
Etac / Cross 5 / www.etac.com User manual Driving technique, maneuvering Parking Turn the castor wheels forwards and activate the brakes. Never park on a slope with a user in the wheelchair. Transferring into/out of the wheelchair Never stand on the... - Page 27 Etac / Cross 5 / www.etac.com User manual The following figures show principles for propelling techniques and how to overcome obstacles like steps and curbs. User, up forwards This technique is recommended only for experienced wheelchair users. – Ensure that the anti-tips are deactivated.
- Page 28 Etac / Cross 5 / www.etac.com User manual Care giver, up forwards – Ensure that the anti-tips are deactivated. Activate the anti-tips afterwards! Care giver, up backwards – Ensure that the anti-tips are deactivated. Activate the anti-tips afterwards! Care giver, down forwards –...
- Page 29 Etac / Cross 5 / www.etac.com User manual Stairs, up We always recommend using two carers for this transfer. One who walks behind and holds on to – Ensure that the anti-tips are deactivated. Never the push handle and one who walks in front and use an escalator, even if a care giver is available.
-
Page 30: Maintenance & Fault-Finding Chart
Etac / Cross 5 / www.etac.com User manual Maintenance Rear wheels: Clean quick release axles as required. Upholstery: Wash, see labels on each item. Tyre pressure: Check the tyre pressure (once/month). In the event of problems, contact your dealer or Technical Aids Centre. -
Page 31: Settings (Cont.)
Etac / Cross 5 / www.etac.com 5. Settings Seat angle The seat angle is dependent on the difference between the front and the rear seat heights. Risk of tipping: Always check the setting of the the anti-tips. If the seat angle is changed: - Adjust the angle of the front fork attachment. -
Page 32: Settings Back Support 3A
Etac / Cross 5 / www.etac.com 6. Settings back support 3A Adjusting back support angle 1. Loosen the nut. 3. Tighten the nut. 2. Adjust the back support angle. Use the position mark- Risk of tipping: Always check the setting of the ings to obtain the same back support angle on the right the anti-tips. -
Page 33: Adjusting Back Support Height And Lumbar Angle
Etac / Cross 5 / www.etac.com 6. Settings back support 3A Adjusting the back support height and lumbar angle 1. Loosen the locking screws (A) max. 1 turn. We recommend that you start adjusting the lumbar angle with the upper eccentric shaft. If a larger angle is 2. -
Page 34: Adjusting Seat Depth Using Lumbar Angle
Etac / Cross 5 / www.etac.com 6. Settings back support 3A Adjusting seat depth using lumbar angle An extended seat depth is achieved by opening 3. If necessary fit seat extender (accessory).. the back support angle (hip) and then the lumbar angle. -
Page 35: Settings Back Support Mod. 2
Etac / Cross 5 / www.etac.com 7. Settings back support mod. 2 Setting back support height The back support height is continuously settable (See “The chairs possibilities”). Loosen the screws (A) 2-3 turns to set the height of the back support. Ensure that both sides are at the... - Page 36 Etac / Cross 5 / www.etac.com 7. Settings back support mod. 2B Setting back support height The back support height is settable (See “The chairs possibilities”). Loosen the screws to set the height of the back sup- port. Tighten the screws.
-
Page 37: Readjustments
Etac / Cross 5 / www.etac.com 8. Readjustments Brake, adjustment The brakes are infinitely settable. 4. Ensure that the brake is straight in the groove and 1. Loosen the screw a couple of turns. tighten the nut. Test the brakes. -
Page 38: Adjusting The Brake Block
Etac / Cross 5 / www.etac.com 8. Readjustments Adjusting the brake block 5 mm Leg support, infinitely angle adjustable Never stand on the foot supports as you may tip the chair! For lifting a wheelchair. swing in the leg supports under the seat, or remove them, and lift using the frame (lower or upper part). -
Page 39: Amputee Leg Support (Option)
Etac / Cross 5 / www.etac.com 8. Readjustments Amputee leg support Never sit on the amputee leg support. When lifting the wheelchair, remove the amputee leg support, swing the other leg support in under the seat (or remove it) and lift using the frame... -
Page 40: Changing The Camber Angle
Etac / Cross 5 / www.etac.com 8. Readjustments Changing the camber angle The camber angle can be changed by changing the When assembling, check so that the rear wheel washers that are mounted between the hub sleeve axle is correctly adjusted. The button in the hub and the nut. -
Page 41: Handrims
Etac / Cross 5 / www.etac.com 8. Readjustments Handrims The way in which the user is able to grip the hand- Be aware that when passing through narrow rims is influenced by the handrim’s material and its spaces there is a risk of getting your fingers distance from the wheel. -
Page 42: Accessories - Adjusting, Handling
Etac / Cross 5 / www.etac.com 9. Accessories - adjusting, handling Assembly instructions are always provided with accessories when they are delivered from Etac.Instruc- tions are also available on our website www.etac.com. Seat cushion and comfort wedge The cushion is cut to the required depth at the front or back edge. -
Page 43: Arm Support, Flip-Up, Height Adjustable
Etac / Cross 5 / www.etac.com 9. Accessories - adjusting, handling Arm support, flip-up, height adjustable The flip-up arm support comes in two varieties, height Never use the arm supports to lift the wheel- adjustable and fixed. It is mounted onto the wheelchair’s chair. -
Page 44: Head Support
Etac / Cross 5 / www.etac.com 9. Accessories - adjusting, handling Head support The head support is mounted onto the bow handle (accessory) or onto a separate head support attach- ment. The head support is adjustable in height, depth and angle, and is detachable. -
Page 45: Technical Data
Etac / Cross 5 / www.etac.com 10. Technical data Seat depth from Item no Weight with rear Type of chair Total width back support Cross 5 wheel user weight tube** 35 cm short 13123001 56,0 cm 36-42 cm 15,0 kg... -
Page 46: Service And Maintenance
If your chair needs reconditioning or repair, only original When necessary lubricate moving parts/joints parts from Etac or components with equal quality, as with bicycle oil or similar. specified in Cross diagrams, should be used. Etac will not... -
Page 47: Tests And Guarantees
To be sorted according to national regulations of 10 years. If the product is intended for use after the service life period specified by Etac, it is the responsibility of the prod- uct owner to ensure product functionality in accordance with... - Page 48 West Midlands B62 8BH www.etac.com United Kingdom Snug Seat, Inc. Tel 800 336 7684 12801 E. Independence Boulevard Fax 704 882 0751 P.O. Box 1739 Information@snugseat.com Matthews, NC 28106, USA www.etac.com Etac Supply Center AB Långgatan 12 SE-334 24 Anderstorp 7 320451 370976...
