OMI6810A DIMENSIONS
Top View
Front View
Rear View
A
Bottom View
B
OMI Operations Manual: OMI6800 Series
11.22
[285.0]
10.63
[270.0]
B
D
E
with your mounting scheme. We
Dimensions are in inches [mm]
F
Side View
0.28
1.65
[7.0]
[41.9]
Cutout Dimensions
IMPORTANT
Dimensions shown are
estimates, and may not work
recommend measuring your
actual cutout dimensions for a
proper fit.
10.71
[272.0]
10
10
