- Page 1 OMI Operations Manual OMI6900BP Light Industrial Panel PC Series Your Industrial Control Solutions Source _____________________ www.maplesystems.com For use with the following: • OMI6900BP Series Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
-
Page 2: Table Of Contents
Operations Manual: OMI6900BP Series TABLE OF CONTENTS COPYRIGHT NOTICE......................3 WARRANTY........................3 TECHNICAL SUPPORT....................3 UNPACKING THE UNIT ....................3 SAFETY PRECAUTIONS ....................4 OVERVIEW OF OMI6900BP SERIES ................5 SPECIFICATIONS AND DIMENSIONAL OUTLINES .............6 SPECIFICATIONS......................6 OMI6912 DIMENSIONS ....................8 OMI6915 DIMENSIONS ....................9 OMI6916 DIMENSIONS .....................10 OMI6918 DIMENSIONS .....................11 OMI6921 DIMENSIONS .....................12... -
Page 3: Copyright Notice
COPYRIGHT NOTICE This manual is a publication of Maple Systems, Inc., and is provided for use by its customers only. The contents of the manual are copyrighted by Maple Systems, Inc.; reproduction in whole or in part, for use other than in support of Maple Systems equipment, is prohibited without the specific written permission of Maple Systems. -
Page 4: Safety Precautions
Operations Manual: OMI6900BP Series SAFETY PRECAUTIONS Please observe the following precautions when installing the OMI6900BP Series Panel PCs. Failure to comply with these restrictions could result in loss of life, serious personal injury, or equipment damage. Warning: Disconnect this equipment from any power before cleaning. Do not use liquid or spray detergents for cleaning. -
Page 5: Overview Of Omi6900Bp Series
Operations Manual: OMI6900BP Series OVERVIEW OF OMI6900BP SERIES The OMI6900BP Series is available in 12.1”, 15.1”, 15.6”, 18.5”, and 21.5” screen sizes. The OMI6900BP is fanless and compact, and is powered by the 6 Generation Intel Core i5-6300U 2.4 GHz dual-core ®... -
Page 6: Specifications And Dimensional Outlines
Operations Manual: OMI6900BP Series SPECIFICATIONS AND DIMENSIONAL OUTLINES The following section contains the Specifications and Dimensional Outlines for the OMI6900BP Series Light Industrial Panel PCs. SPECIFICATIONS Intel 6th Gen Core i5-6300U CPU processor ® ™ System System Chipset System Memory* 1x DDR4 260-pin SO-DIMM 8 GB 2133MHz 2 x USB 3.0 type A... - Page 7 System Options Microsoft Windows© 10 IoT Enterprise 2019 LTSC 64-bit (PKEA) * 8GB RAM Standard; 16GB DDR4 RAM option available; contact Maple Systems for details ** Additional SSD options available; contact Maple Systems for details. Notes Specifications subject to change without notice.
-
Page 8: Omi6912 Dimensions
Operations Manual: OMI6900BP Series OMI6912 DIMENSIONS Power Connector VESA 100 x 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6900BP Series... -
Page 9: Omi6915 Dimensions
Operations Manual: OMI6900BP Series OMI6915 DIMENSIONS Power Connector VESA 100 x 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6900BP Series... -
Page 10: Omi6916 Dimensions
Operations Manual: OMI6900BP Series OMI6916 DIMENSIONS Power Connector VESA 100 x 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6900BP Series... -
Page 11: Omi6918 Dimensions
Operations Manual: OMI6900BP Series OMI6918 DIMENSIONS Power Connector VESA 100 x 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6900BP Series... -
Page 12: Omi6921 Dimensions
Operations Manual: OMI6900BP Series OMI6921 DIMENSIONS Power Connector VESA 100 x 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6900BP Series... -
Page 13: I/O Ports
Ethernet port indicate the activity and transmission state of the network. REMOTE POWER SWITCH CONNECTOR: Two-Position Connector Header, 2.5mm pitch. OMI6900BP Series units include the matching connector plug. Operations Manual: OMI6900BP Series... -
Page 14: Remote Power Switch Configuration Option
OMI6900BP Series is still providing power, simply press your power switch again to boot your OMI6900BP Series unit. When the unit is properly shut down, then it is safe to remove DC power. When DC power is provided to the OMI6900BP Series once again, the unit will automatically boot. -
Page 15: Vesa Mounting
In addition to VESA mounting, your OMI6900BP Series can be mounted in a panel using the mounting holes located on the sides and top of the unit. Use the included clamps to fasten your OMI6900BP Series unit to a panel, cut out to the proper dimensions on the datasheet corresponding to your display size. -
Page 16: Driver Installation
OS Recovery DVD (enclosed with Non-Embedded Operating Systems only) to reinstall Windows as it arrived to you from Maple Systems. You will need to re-activate Windows using the Product Key located on the rear panel of your unit, adjacent to the product label. -
Page 17: Bios Configuration Options
BIOS CONFIGURATION OPTIONS INTRODUCTION The BIOS (Basic Input/Output System) installed in the ROM of your OMI6900BP Series supports Intel® processors. The BIOS provides critical low-level support for standard devices such as disk drives and serial ports. The BIOS also provides a Setup utility program that allows the user to specify system configuration and setting options. -
Page 18: Setting Com1 Function
Operations Manual: OMI6900BP Series SETTING COM1 FUNCTION The OMI6900BP Series Serial Ports are configured by default as RS232, but COM1 can be configured for RS422 (4-wire) or RS485 (2-wire) operation if so desired. Port configuration is managed through the BIOS; see the below table for instructions on changing COM1 port mode. -
Page 19: Windows 10 Iot Enterprise 2019 Ltsc
Media Player WONDERWARE / AVEVA™ EDGE All the OMI6900BP series Panel PCs are compatible with Wonderware / AVEVA™ Edge SCADA software package. The choice of operating system will determine the target platform and runtime license required as shown in the chart below:... - Page 20 Your Industrial Control Solutions Source _____________________ www.maplesystems.com 1010-1115 Rev 00 Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
