OMI Operations Manual

OMI6800B Light Industrial Panel PC Series

Your Industrial Control Solutions Source

_____________________

www.maplesystems.com

For use with the following:

• OMI6800B Series

Maple Systems, Inc. | 808 134

St. SW, Suite 120, Everett, WA 98204 | 425.745.3229

Need help?

Do you have a question about the OMI6821BPHEB and is the answer not in the manual?

Questions and answers

Summary of Contents for Maple Systems OMI6821BPHEB

Page 1 OMI Operations Manual OMI6800B Light Industrial Panel PC Series Your Industrial Control Solutions Source _____________________ www.maplesystems.com For use with the following: • OMI6800B Series Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
Page 2 Operations Manual: OMI6800B Series TABLE OF CONTENTS COPYRIGHT NOTICE......................3 WARRANTY........................3 TECHNICAL SUPPORT....................3 UNPACKING THE UNIT ....................3 SAFETY PRECAUTIONS ....................4 OVERVIEW OF OMI6800B SERIES................5 SPECIFICATIONS AND DIMENSIONAL OUTLINES .............6 SPECIFICATIONS .....................6 SPECIFICATIONS – ENHANCED MODELS.............8 OMI6807 DIMENSIONS ....................9 OMI6808 DIMENSIONS ..................10 OMI6810 DIMENSIONS ..................11 OMI6812 DIMENSIONS ..................12 OMI6815 DIMENSIONS ..................13...
Page 3 COPYRIGHT NOTICE This manual is a publication of Maple Systems, Inc., and is provided for use by its customers only. The contents of the manual are copyrighted by Maple Systems, Inc.; reproduction in whole or in part, for use other than in support of Maple Systems equipment, is prohibited without the specific written permission of Maple Systems.
Page 4 Operations Manual: OMI6800B Series SAFETY PRECAUTIONS Please observe the following precautions when installing the OMI6800B Series Panel PCs. Failure to comply with these restrictions could result in loss of life, serious personal injury, or equipment damage. Warning: Disconnect this equipment from any power before cleaning. Do not use liquid or spray detergents for cleaning.
Page 5 Operations Manual: OMI6800B Series OVERVIEW OF OMI6800B SERIES The OMI6800B Series is available in 7”, 8”, 10.1”, 12.1”, 15.1”, 15.6”, 18.5”, and 21.5” screen sizes. The OMI6800B is fanless and compact with flat panel resistive touch screens, and is powered by the Intel ®...
Page 6 10 IoT Enterprise LTSC 64-bit (PKEA) © * CPU PassMark Benchmark comparison with OMI6800BA Series (Intel Celeron N2930 CPU) ® ™ ** Additional SSD options available; contact Maple Systems for details. Notes Specifications subject to change without notice. Operations Manual: OMI6800B Series...
Page 7 10 IoT Enterprise LTSC 64-bit (PKEA) * CPU PassMark Benchmark comparison with OMI6800BA Series (Intel Celeron N2930 CPU) ® ™ ** Additional SSD options available; contact Maple Systems for details. Notes Specifications subject to change without notice. Operations Manual: OMI6800B Series...
Page 8 Operations Manual: OMI6800B Series SPECIFICATIONS – ENHANCED MODELS Intel Pentium Apollo Lake N4200 Quad-Core 1.1GHz Processor ® ™ ™ System System Chipset System Memory Onboard DDR3L 4 GB 1600 MHz 2 x USB 3.0 type A 1 x RS-232/422/485 DE-9P, COM1 (default RS-232) Serial 1 x RS-232 DE-9P, COM2 Audio...
Page 9 Operations Manual: OMI6800B Series OMI6807 DIMENSIONS Power Connector VESA 75 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series...
Page 10 Operations Manual: OMI6800B Series OMI6808 DIMENSIONS Power Connector VESA 75 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series...
Page 11 Operations Manual: OMI6800B Series OMI6810 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series...
Page 12 Operations Manual: OMI6800B Series OMI6812 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series...
Page 13 Operations Manual: OMI6800B Series OMI6815 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series...
Page 14 Operations Manual: OMI6800B Series OMI6816 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series...
Page 15 Operations Manual: OMI6800B Series OMI6818 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series...
Page 16 Operations Manual: OMI6800B Series OMI6821 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series...
Page 17 Operations Manual: OMI6800B Series I/O PORTS COM1 and COM2: Connector Type: DE9P male serial ports. COM1* COM2 Pin # (RS-232 Default) (RS422) (RS485) (RS232) 422_TX- 485- 422_TX+ 485+ 422_RX+ 422_RX- * Refer to “Setting COM1 Function” section to set the communication mode. LINE OUT: Connector Type: 3.5mm audio jack.
Page 18 OMI6800B Series unit. When the unit is properly shut down, then it is safe to remove DC power. When DC power is provided to the OMI6800B Series once again, the unit will automatically boot. Warning: Maple Systems does not recommend shutting down the OMI6800B Series by cutting DC power to the unit.
Page 19 Tighten the panel bolts with a torque force between 7 ~ 8.5 inch/lbs. to ensure an adequate seal. Torque values outside this range may negate NEMA or IP rating, or cause damage to the unit or panel. Maple Systems is not responsible for damage to unit, mounting surface, or to other components caused by improper mounting.
Page 20 Warning: Changing settings or configurations within the BIOS of your OMI6800B can adversely impact the operation of your unit if incorrectly performed. Maple Systems provides the below instructions solely for the operations specified, and is not responsible for improper unit operation caused by changing settings or entries other than those explicitly listed below.
Page 21 Operations Manual: OMI6800B Series SETTING COM1 FUNCTION The OMI6800B Series Serial Ports are configured by default as RS232, but COM1 can be configured for RS422 (4-wire) or RS485 (2-wire) operation if so desired. Port configuration is managed through the BIOS; see the below table for instructions on changing COM1 port mode. Note: COM1 is the only port that can be configured for RS422 or RS485 operation;...
Page 22 Operations Manual: OMI6800B Series ANALOG RESISTIVE TOUCH SCREEN (Except Enhanced Model Series) The OMI6800B series includes an analog resistive touch screen. An application is pre-loaded onto your OMI6800B which allows you to calibrate and change the settings of the touch screen. RESISTIVE TOUCH SCREEN CALIBRATION The touch screen may need to be recalibrated from time-to-time.
Page 23 Operations Manual: OMI6800B Series 3. For Standard Calibration: • Click this button and arrows appear pointing to red squares. Use your finger or stylus to touch the red squares in sequence. After the fifth red point calibration is complete. 4. For Advanced Calibration: •...
Page 24 Operations Manual: OMI6800B Series 2. Beep Mode: • Enable Beep Sound – turns beep function on and off • Beep on Pen Down – beep occurs when pen comes down • Beep on Pen Up – beep occurs when pen is lifted up •...
Page 25 Operations Manual: OMI6800B Series WINDOWS 10 IoT ENTERPRISE LTSC Windows 10 IoT Enterprise LTSC is a full Professional version of Windows 10, available on all OMI6800B models. This powerful operating system delivers enterprise manageability and security to IoT solutions. Additionally, all the features and functionality that customers expect to find on their desktop PC are available in this version.
Page 26 Your Industrial Control Solutions Source _____________________ www.maplesystems.com 1010-1038 Rev 03 Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
