- Page 1 OMI Operations Manual OMI6800B Light Industrial Panel PC Series Your Industrial Control Solutions Source _____________________ www.maplesystems.com For use with the following: OMI6800B Series Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
-
Page 2: Table Of Contents
Operations Manual: OMI6800B Series TABLE OF CONTENTS COPYRIGHT NOTICE......................3 WARRANTY........................3 TECHNICAL SUPPORT....................3 UNPACKING THE UNIT ....................3 SAFETY PRECAUTIONS ....................4 SPECIFICATIONS AND DIMENSIONAL OUTLINES .............5 OMI6807 DIMENSIONS ....................7 OMI6808 DIMENSIONS ....................8 OMI6810 DIMENSIONS ....................9 OMI6812 DIMENSIONS ....................10 OMI6815 DIMENSIONS ....................11 OMI6816 DIMENSIONS ....................12 OMI6818 DIMENSIONS ....................13... -
Page 3: Copyright Notice
COPYRIGHT NOTICE This manual is a publication of Maple Systems, Inc., and is provided for use by its customers only. The contents of the manual are copyrighted by Maple Systems, Inc.; reproduction in whole or in part, for use other than in support of Maple Systems equipment, is prohibited without the specific written permission of Maple Systems. -
Page 4: Safety Precautions
Operations Manual: OMI6800B Series SAFETY PRECAUTIONS Please observe the following precautions when installing the OMI6800B Series Panel PCs. Failure to comply with these restrictions could result in loss of life, serious personal injury, or equipment damage. Warning: Disconnect this equipment from any power before cleaning. Do not use liquid or spray detergents for cleaning. -
Page 5: Specifications And Dimensional Outlines
Operations Manual: OMI6800B Series SPECIFICATIONS AND DIMENSIONAL OUTLINES The following section contains the Specifications and Dimensional Outlines for the OMI6800B Series Light Industrial Panel PCs. Intel ® Pentium ™ Apollo Lake ™ N4200 Quad-Core 1.1GHz Processor System Chipset System System Memory Onboard DDR3L 4 GB 1600 MHz 2 x USB 3.0 type A... - Page 6 10 IoT Enterprise 2019 LTSC 64-bit (PKEA) © * CPU PassMark Benchmark comparison with OMI6800BA Series (Intel ® Celeron ™ N2930 CPU) ** Additional SSD options available; contact Maple Systems for details. Notes Specifications subject to change without notice. Operations Manual: OMI6800B Series...
-
Page 7: Omi6807 Dimensions
Operations Manual: OMI6800B Series OMI6807 DIMENSIONS Power Connector VESA 75 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series... -
Page 8: Omi6808 Dimensions
Operations Manual: OMI6800B Series OMI6808 DIMENSIONS Power Connector VESA 75 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series... -
Page 9: Omi6810 Dimensions
Operations Manual: OMI6800B Series OMI6810 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series... -
Page 10: Omi6812 Dimensions
Operations Manual: OMI6800B Series OMI6812 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series... -
Page 11: Omi6815 Dimensions
Operations Manual: OMI6800B Series OMI6815 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series... -
Page 12: Omi6816 Dimensions
Operations Manual: OMI6800B Series OMI6816 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series... -
Page 13: Omi6818 Dimensions
Operations Manual: OMI6800B Series OMI6818 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series... -
Page 14: Omi6821 Dimensions
Operations Manual: OMI6800B Series OMI6821 DIMENSIONS Power Connector VESA 100 mm Screw Holes Line Out Remote Power Switch Connector USB 3.0 Host Ports Gigabit Ethernet Ports DE9P COM Ports Operations Manual: OMI6800B Series... -
Page 15: Overview Of Omi6800B Series
Operations Manual: OMI6800B Series OVERVIEW OF OMI6800B SERIES The OMI6800B Series is available in 7”, 8”, 10.1”, 12.1”, 15.1”, 15.6”, 18.5”, and 21.5” screen sizes. The OMI6800B is fanless and compact with flat panel resistive touch screens, and is powered by the Intel ®... -
Page 16: I/O Ports
Ethernet port indicate the activity and transmission state of the network. REMOTE POWER SWITCH CONNECTOR: Two-Position Connector Header, 2.5mm pitch. OMI6800B Series units include the matching connector plug. Operations Manual: OMI6800B Series... -
Page 17: Remote Power Switch Configuration Option
OMI6800B Series is still providing power, simply press your power switch again to boot your OMI6800B Series unit. When the unit is properly shut down, then it is safe to remove DC power. When DC power is provided to the OMI6800B Series once again, the unit will automatically boot. -
Page 18: Vesa Mounting
In addition to VESA mounting, your OMI6800B Series can be mounted in a panel using the mounting holes located on the sides and top of the unit. Use the included clamps to fasten your OMI6800B Series unit to a panel, cut out to the proper dimensions on the datasheet corresponding to your display size. -
Page 19: Driver Installation
OS Recovery DVD (enclosed with Non-Embedded Operating Systems only) to reinstall Windows as it arrived to you from Maple Systems. You will need to re-activate Windows using the Product Key located on the rear panel of your unit, adjacent to the product label. -
Page 20: Bios Configuration Options
BIOS CONFIGURATION OPTIONS INTRODUCTION The BIOS (Basic Input/Output System) installed in the ROM of your OMI6800B Series supports Intel® processors. The BIOS provides critical low-level support for standard devices such as disk drives and serial ports. The BIOS also provides a Setup utility program that allows the user to specify system configuration and setting options. -
Page 21: Setting Com1 Function
Operations Manual: OMI6800B Series SETTING COM1 FUNCTION The OMI6800B Series Serial Ports are configured by default as RS232, but COM1 can be configured for RS422 (4-wire) or RS485 (2-wire) operation if so desired. Port configuration is managed through the BIOS; see the below table for instructions on changing COM1 port mode. -
Page 22: Analog Resistive Touch Screen
ANALOG RESISTIVE TOUCH SCREEN The OMI6800B Series includes an analog resistive touch screen. An application is pre-loaded onto your OMI6800B Series which allows you to calibrate and change the settings of the touch screen. TOUCH SCREEN CALIBRATION The touch screen may need to be recalibrated from time-to-time. There are two calibration methods: ‘Standard Calibration’... -
Page 23: Touch Screen Settings
Operations Manual: OMI6800B Series 3. For Standard Calibration: Click this button and arrows appear pointing to red squares. Use your finger or stylus to touch the red squares in sequence. After the fifth red point calibration is complete. 4. For Advanced Calibration: ... -
Page 24: Touch Screen Edge Compensation
Operations Manual: OMI6800B Series 2. Beep Mode: Enable Beep Sound – turns beep function on and off Beep on Pen Down – beep occurs when pen comes down Beep on Pen Up – beep occurs when pen is lifted up ... -
Page 25: Windows 10 Iot Enterprise 2019 Ltsc
Media Player WONDERWARE / INDUSOFT WEBSTUDIO All the OMI6800B series Panel PCs are compatible with Wonderware / Indusoft Web Studio. The choice of operating system will determine the target platform and runtime license required as shown in the chart below:... - Page 26 Your Industrial Control Solutions Source _____________________ www.maplesystems.com 1010-1038 Rev 00 Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
