  • Page 1 Rockchip RK3399 Platform User’s Manual 1...
  • Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft Windows ® is a registered trademark of Microsoft Corp.  ITE is a trademark of Integrated Technology Express, Inc.  IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines ...
  • Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity RICO-3399  RTC Battery  DC Power Cable  If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
  • Page 5 (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the AAEON.com for the latest version of this document. Preface...
  • Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
  • Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
  • Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
  • Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○...
  • Page 10 China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...

  • Page 11: Table Of Contents

    Table of Contents Chapter 1 - Product Specifications..................1 Specifications......................2 Chapter 2 – Hardware Information ..................4 Dimensions ....................... 5 Jumpers and Connectors..................6 List of Jumpers ......................7 2.5 Turning on/off your BOXER-RK99 ................16 Preface...

  • Page 12: Chapter 1 - Product Specifications

    Chapter 1 - Product Specifications...

  • Page 13: Specifications

    Specifications System 2.5” Board (PICO ITX) Form Factor  Rockchip RK3399 (ARM Dual Cortex-A72 + Processor  Quad Cortex-A53, 1.8GHz) Onboard LPDDR3 2GB RAM System Memory  16GB eMMC and Micro SD card Storage  Power Requirement DC 12 V ...
  • Page 14 Network (LAN) 1 x RJ45, Giga Ethernet  1 x RS232/422/485 D-SUB9 connector Serial Port  1 x RS232 connector 1 x USB2.0, 1 x USB3.0 Type A Dual Ports  1 x USB Type C OTG Video 1 x Audio connector ...

  • Page 15: Chapter 2 - Hardware Information

    Chapter 2 – Hardware Information...

  • Page 16: Dimensions

    Dimensions Chapter 2 – Hardware Information...

  • Page 17: Jumpers And Connectors

    Jumpers and Connectors Chapter 2 – Hardware Information...

  • Page 18: List Of Jumpers

    List of Jumpers Please refer to2.3 List of Jumpers Please refer to the table below for all of the board’s jumpers that you can configure for your application Label Function Power Button Operating Voltage Selection eDP Port LCD Power Backlight Power Control Mode Selection Integrated 2 COM port setting COM port setting...
  • Page 19 +3.3V 2.3.5 JP5: eDP Port Backlight Power Definition +12V 2.3.6 JP6: Integrated2 (220-97-05GB01) Definition Definition +3.3V I2C1_CLK GPIO0 UART4_TX I2C1_DATA GPIO1 GPIO2 UART4_RX GPIO3 2.3.7 JP7/JP8: COM port setting Mode RS422 Open Open RS232 Open Short RS485 Short Short 2.3.8 JP7/JP8: COM port setting Mode RS422 Open...
  • Page 20 List of Connectors Please refer to the table below for all of the board’s connectors that you can configure for your application Label Function CN22 GPIO CN11 eDP Connector I-PEX Connector for WiFi CN19 Integrated Debug Port CN16 DC-IN 12V Power CN15 Speaker CN21...
  • Page 21 2.4.1 CN22: GPIO (220-97-05GB01) Definition Definition GPO0 GPI2 GPI0 GPO3 GPO1 GPI3 GPI1 +3.3V GPO2 2.4.2 CN11: eDP (20455-030E-12) Definition Definition Definition eDP_HPD eDP_TX0- LCD_PWR BKL_ENABLE eDP_TX0+ LCD_PWR BKL_CONTROL eDP_TX3- eDP_TX1- eDP_TX3+ BKL_PWR eDP_TX1+ (Refer to JP2) BKL_PWR eDP_AUX- (Refer to JP2) BKL_PWR eDP_TX2- eDP_AUX+...
  • Page 22 I2C4_CLK USB1_D- I2C4_DATA I2C3_CLK I2C3_DATA NFC_DFU USB1_D+ 2.4.5 CN8: Debug port (712-71-09TW01) Definition Definition 2.4.6 CN16: DC 12V Power Definition +12V 2.4.7 CN15: Speaker(712-H71-105W01) Definition HP_DET LEFT_OUT RIGHT_OUT Spk_L_P Chapter 2 – Hardware Information...
  • Page 23 Spk_L_N Spk_R_P Spk_R_N 2.4.8 CN21: RS232 (220-97-05GB01) Definition Definition Vout(refer to JP3) 2.4.9 CN9: Giga LAN (RJJL4A-4WH1-FP0-0R 90D(F)) Definition Definition TX+_D1 BI-_D3 TX-_D1 RX-_D2 RX+_D2 BI+_D4 BI+_D3 BI-_D4 2.4.10 CN5: RS232/422/485 (220-97-05GB01) Definition Definition Vout(refer to JP3) 2.4.11 CN6: USB (1201-700-08S) Chapter 2 –...
  • Page 24 Definition Definition USB2_D- USB3_D- USB2_D+ USB3_D+ 2.4.12 CN13: HDMI type A(QJ51191-LFB4-7F) Definition Definition HDMI_TX2P HDMI_CLKN HDMI_TX2N HDMI_CEC HDMI_TX1P DDC_SCL HDMI_TX1N DDC_SDA HDMI_TX0P HDMI_TX0N HDMI_HPD HDMI_CLKP 2.4.13 CN7: USB TYPE C OTG(TMC106-USBD05-835) Definition OTG_USB_D- OTG_USB_D+ OTG_ID Chapter 2 – Hardware Information...
  • Page 25 2.4.14 CN14: uSD (112J-TDAR-R) Definition Definition DAT2 DAT3 DAT0 DAT1 +3.3V 2.4.15 CN3H3: WWAN card slot (AS0B22x-S56Q-7H) Definition Definition Definition Definition WAKE_UP USIM_RESET +3.3V +3.3V WAKE_UP_OUT DISABLE Chapter 2 – Hardware Information...
  • Page 26 Definition Definition Definition Definition USIM_PWR RESET USIM_DATA USB1_D- +3.3V USIM_CLK USB1_D+ +3.3V +3.3V the table below for all of the board’s jumpers that you can configure for your application Chapter 2 – Hardware Information...

  • Page 27: 2.5 Turning On/Off Your Boxer-Rk99

    2.5 Turning on/off your BOXER-RK99 1. Connect your BOXER-RK99 to other devices before you connect power. 2. Turning On the Device: Plug the power adapter to the power source, and then connect the power adapter to the power socket of your BOXER-RK99.
