Operator's Manual
Vector™ Multi-Cook Oven
Structured Air Technology™
VMC-F3E
VMC-F4E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vector VMC-F3E and is the answer not in the manual?

Questions and answers

Related Manuals for Alto-Shaam Vector VMC-F3E

Summary of Contents for Alto-Shaam Vector VMC-F3E

  • Page 1 Operator’s Manual Vector™ Multi-Cook Oven VMC-F3E VMC-F4E Structured Air Technology™ MN-39279-EN REV.01 5/18 alto-shaam.com...

  • Page 2: Manufacturer's Information

    © Copyright 5/18 by Alto-Shaam, Inc. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Alto-Shaam, Inc. Trademarks All trademarks referenced in this documentation are the property of their respective owners.

  • Page 3: Foreword

    OREWORD Enjoy your Alto-Shaam Vector Oven! Structured Air The Alto-Shaam Vector Oven features Structured Air Technology, giving you two, Technology™ three or four ovens in one. It gives you the flexibility to simultaneously cook a variety of menu items with no flavor transfer. It provides the ability to control temperature, fan speed, and time in each individual oven chamber.
  • Page 4 OREWORD Ve ctor ™ F Series O p e r a tor’ s Man u a l MN-39279 Rev 01 5 /18 ▪ ▪ ▪ ▪...

  • Page 5: Table Of Contents

    Foreword Enjoy your Alto-Shaam Vector Oven! ....3 Extend Your Manufacturer’s Warranty ....3 Alto-Shaam 24/7 Emergency Repair Service .
  • Page 6 ABLE OF ONTENTS How to Enable Manual Mode, Linking, and Set Temp Function ..82 How to Change the Time and Date Settings ....85 How to Change the Sound Settings.

  • Page 7: Safety

    AFETY The Meaning of Signal Words Technical content produced by Alto-Shaam contains signal words where needed. These signal words must be obeyed to reduce the risk of death, personal injury, or equipment damage. The meaning of these signal words is explained below.

  • Page 8: Appliance Description And Intended Use

    AFETY Appliance Description and Intended Use Structured Air Alto-Shaam Vector’s Structured Air Technology system allows for multiple, Technology™ unique cooking chambers within the same oven. Air is delivered by a blower located in the rear of each cooking chamber. Air travels vertically through the jet plates into each chamber.

  • Page 9: Safety Precautions

    Keep this manual and all supplied instructions, diagrams, schematics, parts lists, ▪ notices, and labels with the appliance if the appliance is sold or moved to another location. Contact Alto-Shaam for additional training if needed. ▪ Vecto r™ F Ser ie s Ope rator ’ s Ma n ua l...
  • Page 10 Alto-Shaam of all liability. To prevent serious injury, death or property damage, have the appliance ▪...

  • Page 11: Labels

    ABELS Label Locations lmno VMC-PHD-003121 Vecto r™ F Ser ie s Ope rator ’s Ma nual MN-392 79 Re v 0 1 5/18 ▪ ▪ ▪ ▪...
  • Page 12 ABELS Made in U.S.A. Pull the knob out when cooking with combined chambers. Push the knob in when cooking with all chambers. LA-39431 WARNING Hot surface WARNING WARNING/ADVERTENCIA/AVERTISSEMENT Electric shock hazard Electric Shock Hazard To reduce the risk of electric shock, do not remove or open cover.
  • Page 13 ABELS Check fans Check fans Compruebe los ventiladores Vérifiez les ventilateurs LA-39033 LA-39280 WARNING WARNING / ADVERTENCIA / AVERTISSEMENT Burn hazard Burn hazard. Always load liquids, or foods that can become liquid when heated, at an eye level where they can be seen. Always load liquids, or foods that can become liquid Peligro de quemaduras.
  • Page 14 150 VCA par rapport à la terre. For use on individual branch circuits only. U liser exclusivement sur des circuits de dériva on propres. LA-38852 Every Alto-Shaam product is precision calibrated prior to release from the factory to ensure accurate temperature control. Line 1 supply terminal...
  • Page 15 ABELS Ground terminal LA-36443-G Equipotential terminal LA-36443-E Press and release the high limit temperature reset buttons. VMC-H2, VMC-H3, VMC-H4 VMC-F3, VMC-F4 VMC-H2H, VMC-H3H, VMC-H4H LA-39715 Vecto r™ F Ser ie s Ope rator ’ s Ma n ua l MN-392 79 Re v 0 1 5/18 ▪...
  • Page 16 ABELS Ve ctor ™ F Series O p e r a tor’ s Man u a l MN-39279 Rev 01 5 /18 ▪ ▪ ▪ ▪...

  • Page 17: Installation

    NSTALLATION Dimensions Drawing Vecto r™ F Ser ie s Ope rator ’s Ma nual MN-392 79 Re v 0 1 5/18 ▪ ▪ ▪ ▪...

  • Page 18: How To Receive The Appliance

    Alto-Shaam policy It is the policy of Alto-Shaam to assist customers in collecting claims that have been properly filed and actively pursued. Alto-Shaam cannot, however, file damage claims, assume the responsibilities for damage claims, or accept deductions in payment for damage claims.

  • Page 19: How To Unpack The Oven

    Examine the appliance for damage. If the appliance has been damaged, do not use the appliance until it has been inspected by an authorized service provider. Contact your carrier or Alto-Shaam customer service. Remove the plastic wrap. the retaining straps.

  • Page 20: Installation Checklist

    NSTALLATION Installation Checklist Installation of the oven is to be completed only by an authorized Alto-Shaam service partner. Place this form with the oven’s records. WARNING: Electric shock and arc flash hazard. Use caution when measuring line voltage. Wear Personal Protective Equipment (PPE).
  • Page 21 NSTALLATION Continued from previous page Electrical: Record Measure the voltage at the wall outlet. L1 to L2: L1 to L3: L2 to L3: Measure the voltage at the oven’s main disconnect switch. L1 to L2: L1 to L3: L2 to L3: Measure the voltage at the oven’s main terminal block.

  • Page 22: How To Install The Oven (60 Hz Models Without Cords Or Plugs)

    NSTALLATION How to Install the Oven (60 Hz Models Without Cords or Plugs) Before you begin Make sure you have: Screwdriver (Phillips #2) ▪ Nut driver (1/4-inch) ▪ An appropriate lifting device, and enough personnel, to safely move and position ▪...
  • Page 23 NSTALLATION Position the oven To position the oven, do the following. Step Action Make sure that: The location where the oven is being installed is rated to support the ▪ weight of the oven, The oven is within five feet of the appropriate electrical outlet, ▪...
  • Page 24 NSTALLATION Continued from previous page Connect the wiring To connect the wiring, do the following. the main disconnect switch to the OFF position. VMC-TS-003497 Remove the side panel WARNING: Electric shock hazard. Make sure the supply cord is not connected to a power supply.
  • Page 25 NSTALLATION Continued from previous page Remove the knockout plate Remove the necessary knockout from the knockout plate. VMC-TS-003503 Slide the supply cord through the cord grip. Install the supply cord and cord grip into the knockout plate VMC-TS-003506 Re-install the knockout plate. Do not tighten the cord grip sealing nut. Install the supply cord into the oven far enough to reach the ground terminal block.
  • Page 26 NSTALLATION Continued from previous page Connect the wires to the appropriate terminals (L1, L2, L3, etc.) of the main disconnect switch in accordance with local codes and regulations. Install the ground wire to the ground terminal. VMC-TS-003512 VMC-TS-003115  NOTE: The equipotential-bonding terminal is located at the bottom rear of the oven.
  • Page 27 NSTALLATION Continued from previous page Press reset buttons Press and release the high limit temperature reset buttons Remove the tag VMC-F3, VMC-F4 VMC-TS-003921 Requirements for Any appliance that is not furnished with a power supply cord must be installed restraining with a restraining device (tether).

  • Page 28: How To Install The Oven (Canada Models Only)

    NSTALLATION How to Install the Oven (Canada Models Only) Before you begin Make sure you have: Screwdriver (Phillips #2) ▪ Nut driver (1/4-inch) ▪ An appropriate lifting device, and enough personnel, to safely move and position ▪ the weight of the oven. VMC-F3E: 472 lb (214 kg) □...
  • Page 29 NSTALLATION Position the oven To position the oven, do the following. Step Action Make sure that: The location where the oven is being installed is rated to support the ▪ weight of the oven, The oven is within five feet of the appropriate electrical outlet, ▪...
  • Page 30 NSTALLATION Continued from previous page Connect the wiring To connect the wiring, do the following. the main disconnect switch to the OFF position. VMC-TS-003731 Connect the supply cord to a power source in accordance with local codes and regulations. VMC-TS-003734 VMC-TS-003115 ...
  • Page 31 NSTALLATION Continued from previous page Press reset buttons Press and release the high limit temperature reset buttons Remove the tag VMC-F3, VMC-F4 VMC-TS-003924 Requirements for Any appliance that is not furnished with a power supply cord must be installed restraining with a restraining device (tether).

  • Page 32: How To Install The Oven (380-415 Volt 50/60 Hz Models Without Cords Or Plugs)

    NSTALLATION How to Install the Oven (380-415 Volt 50/60 Hz Models Without Cords or Plugs) Before you begin Make sure you have: Appropriate cord, minimum oil resistant HO7RN-F. See local codes and ▪ regulations. Screwdriver (Phillips #2) ▪ Nut driver (1/4-inch) ▪...
  • Page 33 NSTALLATION Continued from previous page Wire sizes 60335-1 IEC:2010 Rated current of appliance Nominal cross-sectional area >0.2 – ≤3 >3 – ≤0 0.75 >6 – ≤10 >10 – ≤16 >16 – ≤25 >25 – ≤32 >32 – ≤40 >40 – ≤63 Position the oven To position the oven, do the following.
  • Page 34 NSTALLATION Continued from previous page Level the oven To level the oven, do the following. Check the level of the oven using a spirit (bubble) level. Check front to back and side to side. VMC-TS-003057 Adjust the legs, if necessary, to achieve levelness. The oven is now level.
  • Page 35 NSTALLATION Continued from previous page Remove the 4 screws holding the main disconnect switch to the oven. Position the terminal block assembly with the main disconnect switch terminal screws facing up. VMC-TS-003500 Remove the knockout plate Remove the necessary knockout from the knockout plate. VMC-TS-003503 Slide the supply cord...
  • Page 36 NSTALLATION Continued from previous page Re-install the knockout plate. Do not tighten the cord grip sealing nut. Install the supply cord into the oven far enough to reach the ground terminal block. VMC-TS-003509 Connect the wires to the appropriate terminals (L1, L2, L3, etc.) of the main disconnect switch in accordance with local codes and regulations.
  • Page 37 NSTALLATION Continued from previous page Re-install the main disconnect switch. Re-install the 4 screws holding the main disconnect switch to the oven. Re-install the terminal block assembly. Tighten the cord grip sealing nut onto the supply cord. Re-install the side panel. Press reset buttons Press and release the high limit temperature reset buttons...

  • Page 38: How To Install The Oven On A Stand And Stack The Ovens

    NSTALLATION How to Install the Oven on a Stand and Stack the Ovens Before you begin Make sure you have: The appropriate stand for your oven ▪ Regulation UL 197, 91.8 ▪ An appropriate lifting device, and enough personnel, to safely move and position ▪...
  • Page 39 NSTALLATION Continued from previous page Connect the oven to the stand with the supplied bolts CAUTION: Crushing hazard. If the stand has casters, lock the casters to prevent the oven from moving during installation. VMC-TS-003808 Special requirements Install the tether to the lower oven when installing a stacked set of ovens. for ovens on casters The tether must be connected to the building’s structure and in such a manner that limits the movement of the appliance so no stress is transmitted...
  • Page 40 NSTALLATION Continued from previous page Remove the top screws from the back panel of the lower oven. VMC-TS-003814 Install the stacking bracket VMC-TS-003817 Result The ovens are now stacked. Ve ctor ™ F Series O p e r a tor’ s Man u a l MN-39279 Rev 01 5 /18...

  • Page 41: How To Install The Oven On A Mobile Base

    NSTALLATION How to Install the Oven on a Mobile Base Before you begin Make sure you have: An appropriate lifting device, and enough personnel, to safely move and position ▪ the weight of the oven. VMC-F3E: 472 lb (214 kg) □...
  • Page 42 NSTALLATION Continued from previous page Position the mobile base with the opening facing the front of the oven. Install the mobile base and tighten the 4 bolts VMC-TS-003915 Install the casters onto the mobile base.  NOTE: Install the locking casters at the front of the oven.

  • Page 43: Operation

    PERATION How to Turn On and Turn Off the Oven Before you begin The oven must be connected to electric power. Turning on the oven To turn on the oven, do the following. Step Action the main disconnect switch to the ON position. Press the ON/OFF button .
  • Page 44 PERATION Continued from previous page Turning off the oven To turn off the oven, do the following. Press and hold the ON/OFF button until the LED illuminates red. The oven activates the blowers for the cool down process. The screen displays a cool down prompt and asks for the door to be opened.

  • Page 45: How To Set Preheat Temperatures

    PERATION How to Set Preheat Temperatures Before you begin Make sure the door is closed. ▪ The oven must be turned on (screen is on). ▪ Factory preset preheat temperature for each chamber is 350°F (177°C). ▪ Procedure To set the preheat temperatures, do the following. Step Action Touch...
  • Page 46 PERATION Continued from previous page Touch the Temps icon . The Set Preheat Temperatures screen displays. Select chamber to set its User Configuration preheat temperature Chamber 1 450°F Temps Chamber 2 350°F Chamber 3 250°F °F Chamber 4 350°F Temp Units Clean Oven Info VMC-TS-003180...
  • Page 47 PERATION Continued from previous page Touch the green check mark Select chamber to set its preheat temperature Chamber 1 450°F Chamber 2 350°F Chamber 3 250°F Chamber 4 350°F VMC-TS-003186 Touch the up arrow then the back arrow to return to the home screen. User Configuration User Configuration Temps...

  • Page 48: How To Preheat The Oven

    PERATION How to Preheat the Oven Before you begin Make sure the door is closed. ▪ The oven must be connected to electric power. ▪ The oven chambers should be empty. ▪ All chambers To preheat all chambers simultaneously, do the following. simultaneously Step Action...
  • Page 49 PERATION Continued from previous page Individual chambers To preheat individual chambers separately, continue. separately Touch the chamber icon . The check mark signifies the chosen chamber.  NOTE: The Set Temp function must be enabled. See topic How to Enable Manual Mode, Linking, and Set Temp Function.
  • Page 50 PERATION Length of time to It takes approximately 10-15 minutes (dependent upon the set temperature) for preheat the oven to reach temperature. As each chamber reaches its set temperature, it starts a countdown from 5 minutes to let the temperature stabilize. After that, the screen displays READY to indicate that the chamber is ready for cooking.

  • Page 51: How To Cook In Manual Mode

    PERATION How to Cook in Manual Mode Before you begin Make sure the door is closed. ▪ Be sure the oven is warmed up. Refer to topic How to Preheat the Oven. ▪ The Manual function must be enabled. See topic How to Enable Manual Mode, ▪...
  • Page 52 PERATION Continued from previous page Touch the temperature setting Enter the cooking temperature using the number pad. Touch the green check mark. Enter Temperature (°F) Preheat Ready Manual Program 450°F Manual 15:00 Ready 350°F Manual 00:00 Ready 300°F Manual 450°F Ready VMC-TS-003247 ...
  • Page 53 PERATION Continued from previous page Touch the green start icon . The timer starts counting. Pressing the X icon stops the timer. The timer resets to 0. Preheat Preheat Preheat 15:00 9:15 Done Manual Program Manual Program Manual Program 00:00 00:00 Manual 15:00...

  • Page 54: How To Use The Dual Timers

    PERATION How to Use the Dual Timers Before you begin Make sure the door is closed. ▪ Refer to topic How to Cook in Manual Mode ▪ Background There may be times when you will want to use the same chamber to cook two pans of food at the same time, but at different intervals.
  • Page 55 PERATION Continued from previous page Enter the time for the second pan of food. Enter Cook Time Preheat Ready Manual Program 450°F Manual 00:00 Ready 350°F Manual 00:00 Ready 300°F Manual 450°F Ready 225°F Manual VMC-TS-003258 Touch the temperature setting Enter the cooking temperature using the number pad.
  • Page 56 PERATION Continued from previous page Touch Air Speed Enter the air flow in percentage 10–100% using the number pad. Touch the green check mark.  NOTE: The Air Speed icon will flash until a value is entered. You must enter values for time, temperature, and air speed.
  • Page 57 PERATION Continued from previous page Open the door and load pan 2 when it is ready. Close the door. Touch the green start icon . The timer for pan 2 will start counting. Pressing the X icon stops the timer. The timer resets to 0. Preheat Preheat 9:15...

  • Page 58: How To Cook With Programmed Recipes

    PERATION How to Cook with Programmed Recipes Before you begin Make sure the door is closed. ▪ Be sure the oven is preheated ▪ Be sure your food is prepared and ready to cook ▪ Procedure To cook using a programed recipe, do the following. Step Action Select...
  • Page 59 PERATION Continued from previous page Open the door and load the food into the selected chamber. Close the door. Touch the recipe . The oven starts cooking. During the cooking The screen indicates the time remaining. process Link Preheat Cooking 3:00 Biscuits 3:00...
  • Page 60 PERATION Continued from previous page Result At the end of the cooking process, the oven sounds an alert and the chamber light flashes. The DONE screen displays. Link Preheat Done Biscuits Done Ready 350°F Program Please Remove Food Ready 300°F Program Ready 225°F...

  • Page 61: How To Cook With Linked Chambers

    PERATION How to Cook with Linked Chambers Before you begin Make sure the door is closed. ▪ The selected chambers must be warmed up to the temperature of the recipe. ▪ Refer to topic How to Preheat the Oven. The Link function must be enabled. See topic How to Enable Manual Mode, ▪...
  • Page 62 PERATION Continued from previous page Touch the chambers you want to link. Touch the green check mark  NOTE: Pressing All On selects all chambers. ∞ Chambers with a icon are linked Link Preheat Link Link Link Select chambers to link Ready 350°F Program...
  • Page 63 PERATION Continued from previous page Open the door and load the selected chambers. Touch the recipe . The Cooking screen displays and the cooking process starts. Link Preheat Link Preheat Ready to Cook Cooking Ready 3:00 Manual Program 450°F Program Biscuits Bisc Biscu...

  • Page 64: How To Cook Using Combined Chambers

    PERATION How to Cook Using Combined Chambers Before you begin Be sure your food is prepared and ready to cook ▪ Procedure To cook using combined chambers, do the following. Step Action Remove the jet plates that are between the two chambers to be combined.
  • Page 65 PERATION Continued from previous page Select the chamber . The check mark indicates the chosen chamber. Navigate to the recipe using the arrows . Recipes are sorted first by set temperature and then alphabetically. Ready to Co Ready 350°F 350°F Program Program French toast...
  • Page 66 PERATION Continued from previous page During the cooking The screen indicates the time remaining. process Preheat Cooking 1:30 Roast 1:30 Roast Ready P175 F 300°F Program Ready 225°F Program VMC-TS-003494 The menu area displays details on the current cook setting. ▪...

  • Page 67: How To Cook Using A Probe

    PERATION How to Cook Using a Probe Before you begin Be sure your food is prepared and ready to cook ▪ Procedure To cook using a probe, do the following. Step Action Remove the jet plates that are between the two chambers to be combined.
  • Page 68 PERATION Continued from previous page Select the chamber . The check mark indicates the chosen chamber. Navigate to the recipe using the arrows . Recipes are sorted first by set temperature and then alphabetically. Ready to Co Ready 350°F 350°F Program Program French toast...
  • Page 69 PERATION Continued from previous page During the probe The screen indicates the elapsed time of the probe cook. When the internal food cooking process temperature is reached, the probe cook is complete. The recipe continues to cook any additional stages. Preheat Cooking 1:30...

  • Page 70: How To Create And Edit Recipes

    PERATION How to Create and Edit Recipes Before you begin You will need to know the pass code. The pass code set at the factory is 12345. Procedure To create or edit a recipe, do the following. Step Action Touch the gear icon .
  • Page 71 PERATION Continued from previous page Touching the new recipe icon or touching an existing recipe allows access to the following: Recipe name ▪ Temperature for each stage ▪ Time for each stage ▪ Air speed for each stage ▪ Number of stages (By default, stages 2 and 3 have a length of zero.) ▪...

  • Page 72: How To Create And Edit Recipe Folders

    PERATION How to Create and Edit Recipe Folders Before you begin You will need to know the pass code. The pass code set at the factory is 12345. Procedure To create or edit a recipe folder, do the following. Step Action Touch the gear icon...
  • Page 73 PERATION Continued from previous page Create a new folder or edit an existing folder. Touch the recipes you want to add to the folder. Edit Folder New Folder Touch a recipe to add or remove Touch a recipe to add or remove from folder from folder Touch here to create folder...

  • Page 74: How To Load Recipes From A Usb Drive

    PERATION How to Load Recipes from a USB Drive Before you begin Create a backup file of your current recipes before loading new recipes. ▪ You will need a USB drive loaded with recipes. ▪ You will need to know the pass code. The pass code set at the factory is 12345. ▪...
  • Page 75 PERATION Continued from previous page Plug the USB drive into the port VMC-TS-003314 Touch Load Recipes . The Enter Pass Code screen displays. Enter the pass code 12345 Touch the green check mark USB Functions Enter Pass Code 1 2 3 4 5 # Update CB Update IB H4-XX.XX...
  • Page 76 PERATION Continued from previous page Loading/reading the The oven loads the selected config file (recipe). The Loading Config File screen recipes displays. Load Config Loading configuration file (.ai2) VMC-TS-003323 The oven turns off after the recipes are loaded. Result The recipes are now loaded. Ve ctor ™...

  • Page 77: How To Save Recipes To A Usb Drive

    PERATION How to Save Recipes to a USB Drive Before you begin You will need a USB drive. ▪ You will need to know the pass code. The pass code set at the factory is 12345. ▪ Procedure To download recipes from the oven to a USB drive, do the following. Step Action Touch...
  • Page 78 PERATION Continued from previous page Plug the USB drive into the port VMC-TS-003314 Touch Save Recipes . The Enter Pass Code screen displays. Enter the pass code 12345 Touch the green check mark USB Functions Enter Pass Code 1 2 3 4 5 # Update CB Update IB H4-XX.XX...
  • Page 79 PERATION Continued from previous page Touch the cancel icon then the back arrow to return to the home screen. User Configuration User Configuration Temps Service Sounds °F Temp Units Clean Time Recipes Oven Info Logs VMC-TS-003338 Remove the USB drive. Result The recipes are now saved to the USB drive.

  • Page 80: How To Turn On And Turn Off The Chambers

    PERATION How to Turn On and Turn Off the Chambers Before you begin The oven must be connected to electric power. Turning off a To turn off a chamber, do the following. chamber Step Action Touch and hold the chamber icon .
  • Page 81 PERATION Continued from previous page Turning on a To turn on a chamber, do the following. chamber Touch the chamber icon . The check mark signifies the chosen chamber. Touch the Set Temp icon . The Enter Temperature screen displays. Enter the temperature using the number pad.

  • Page 82: How To Enable Manual Mode, Linking, And Set Temp Function

    PERATION How to Enable Manual Mode, Linking, and Set Temp Function Before you begin The oven must be turned on (screen is on). Procedure To enable the Set Temp, Linking, or Manual mode, do the following. Step Action Touch the gear icon .
  • Page 83 PERATION Continued from previous page Touch the down arrow . The third User Configuration screen displays. User Configuration User Configuration Temps Set Temp Link °F Temp Units Clean Manual Oven Info VMC-TS-003355 Touch the function you want to enable: Set Temp, Link, or Manual icon The Enter Pass Code screen displays.
  • Page 84 PERATION Continued from previous page Touch the back arrows to return to the home screen. User Configuration User Configuration Temps Service Sounds °F Temp Units Clean Time Recipes Oven Info Logs VMC-TS-003189 Result Set Temp, Linking, or Manual mode is now enabled. Ve ctor ™...

  • Page 85: How To Change The Time And Date Settings

    PERATION How to Change the Time and Date Settings Procedure To change the time and date settings, do the following. Step Action Touch the gear icon . The User Configuration screen displays. User Configuration Link Preheat Ready to Preheat Service Sounds Bacon French toas...
  • Page 86 PERATION Continued from previous page Touch the green check mark when finished. Touch the back arrow to return to the home screen. Edit Date and Time User Configuration Service Sounds Time Recipes Logs VMC-TS-003368 Result The time and date have been changed. Ve ctor ™...

  • Page 87: How To Change The Sound Settings

    PERATION How to Change the Sound Settings Procedure To change the sound settings, do the following. Step Action Touch the gear icon . The User Configuration screen displays. User Configuration Link Preheat Ready to Preheat Service Sounds Bacon French toas Fried eggs Time Biscuits...

  • Page 88: How To Change The Temperature Scale

    PERATION How to Change the Temperature Scale Procedure To change the temperature scale from °F to °C and vice versa, do the following. Step Action Touch the gear icon . The User Configuration screen displays. User Configuration Link Preheat Ready to Preheat Service Sounds Bacon...
  • Page 89 PERATION Continued from previous page Touch the back arrows to return to the home screen. User Configuration User Configuration Temps Service Sounds °F Temp Units Clean Time Recipes Oven Info Logs VMC-TS-003385 Result The temperature scale has now been changed. Vecto r™...

  • Page 90: How To Set The Cleaning Timer

    PERATION How to Set the Cleaning Timer Before you begin To help you remember when to clean the oven, the number of hours until the next cleaning may be programmed into the controller. Procedure To set the cleaning timer, do the following. Step Action Touch...
  • Page 91 PERATION Continued from previous page Touch the Clean icon . The Enter Pass Code screen displays. Enter the pass code 12345 Touch the green check mark Enter Pass Code User Configuration 1 2 3 4 5 # Temps °F Temp Units Clean Oven Info VMC-TS-003393...
  • Page 92 PERATION Continued from previous page Touch the up arrow then the back arrow to return to the home screen. User Configuration User Configuration Temps Service Sounds °F Temp Units Clean Time Recipes Oven Info Logs VMC-TS-003399 The cleaning timer is now set. To view the cleaning During the start-up process: hours...

  • Page 93: How To Adjust The Oven Light Duration

    PERATION How to Adjust the Oven Light Duration Before you begin The oven must be turned on (screen is on). Procedure To adjust the oven light duration, do the following. Step Action Touch and hold the oven light icon . The Enter Pass Code screen displays. Enter the pass code 12345 Touch...

  • Page 94: How To View The Oven Logs

    PERATION How to View the Oven Logs Before you begin The oven must be turned on (screen is on). Procedure To view the oven logs, do the following. Step Action Touch the gear icon . The User Configuration screen displays. User Configuration Link Preheat...
  • Page 95 PERATION Continued from previous page Touch Press here to see log details . The logs display. Touch the up and down arrows to scroll through the logs. Logs Logs XX/XX/XX XX:XX:XX – 3 GRILLED CHIC XX/XX/XX XX:XX:XX – 2 GRILLED CHIC Touch here to see logs details re to se XX/XX/XX XX:XX:XX –...
  • Page 96 PERATION Continued from previous page Touch the back arrow to return to the home screen. User Configuration Service Sounds Time Recipes Logs VMC-TS-003428 Result The oven logs have now been viewed. Ve ctor ™ F Series O p e r a tor’ s Man u a l MN-39279 Rev 01 5 /18...

  • Page 97: Maintenance

    AINTENANCE How to Clean the Oven Before you begin WARNING: Electric shock hazard. Set the main disconnect switch to the OFF position to remove electric power from the appliance. CAUTION: Burn hazard. Allow the oven, utensils, and racks to cool before cleaning. CAUTION: Corrosive materials hazard.
  • Page 98 AINTENANCE Continued from previous page Weekly cleaning To clean the oven weekly, do the following. procedure Step Action the main disconnect switch to the OFF position. Make sure the oven is cool—chambers are less than 140°F (60°C). VMC-TS-003133 Spray the exterior areas of the oven with EcoLab Greaselift™ or Chemco Dirt Buster III™...
  • Page 99 AINTENANCE Continued from previous page Monthly cleaning To clean the oven monthly, do the following. procedure Step Action the main disconnect switch to the OFF position. Make sure the oven is cool—chambers are less than 140°F (60°C). Remove the cooking racks and jet plates CAUTION: Personal injury hazard.
  • Page 100 AINTENANCE Continued from previous page Cleaning the filters Remove the filters VMC-TS-003171 Clean the filters in a dishwasher.  NOTE: Replace the filters at least once a year. Re-install the filters. the main disconnect switch to the ON position when complete. Result The oven is now clean.

  • Page 101: Troubleshooting

    ROUBLESHOOTING What to do if the Oven Malfunctions Background You may need to do a factory reset in the case that the oven malfunctions for any ▪ of these issues: The display freezes □ The controls do not respond □ The oven does not heat □...

  • Page 102: What To Do If The Fan Indicator Light Illuminates

    ROUBLESHOOTING What to do if the Fan Indicator Light Illuminates Procedure If the fan indicator light illuminates, do the following. Step Action Turn off the oven and allow it to cool. Remove the filters VMC-TS-003153 Clean the filters in a dishwasher. Re-install the filters.

  • Page 103: What To Do If The High Limit Screen Displays

    ROUBLESHOOTING What to do if the High Limit Screen Displays Procedure If the high limit screen displays , do the following. Step Action Press and release the high limit temperature reset buttons Link Preheat Ready to Preheat High Limit Bacon French toast Fried eggs Biscuits...
  • Page 104 ROUBLESHOOTING Ve ctor ™ F Series O p e r a tor’ s Man u a l MN-39279 Rev 01 5 /18 ▪ ▪ ▪ ▪...

  • Page 105: Warranty

    ARRANTY Warranty Introduction Alto-Shaam, Inc. warrants to the original purchaser only, that any original part found to be defective in material or workmanship will be replaced with a new or rebuilt part at Alto-Shaam's option, subject to provisions hereinafter stated.
  • Page 106 No person except an officer of Alto-Shaam, Inc. is authorized to modify this warranty or to incur on behalf of Alto-Shaam any other obligation or liability in connection with Alto-Shaam equipment.
