Revision History
Date
Version
2017.04
V1.5
2017.04
V1.4
2017.03
V1.3
2017.03
V1.2
2016.12
V1.1
2016.12
V1.0
Espressif Systems
Release notes
Added a note in Section Strapping Pins.
Added the ESP-WROOOM-32 module's dimensional tolerance.
Updated Section Strapping Pins;
Updated Figure ESP32 Pin Layout (for QFN 5*5);
Updated Figure ESP32-WROOM-32 Module;
Updated Figure ESP32-DevKitC Pin Layout.
Updated the notice to Table ESP32 Pin Description;
Added a note to Table ESP32-WROOM-32 Pin Definitions.
Updated Chapter Overview;
Updated Figure Function Block Diagram;
Updated Chapter Pin Definitions;
Updated Section Power Supply;
Updated Section RF;
Updated Figure ESP32-WROOM-32 Pin Layout;
Updated Table ESP32-WROOM-32 Pin Definitions;
Updated Section Notes.
Updated Table UART to Wi-Fi Smart Device.
First release.
