4. Applications
4.3 ESP-Mesh Application—ESP32-MeshKit
ESP32-MeshKit is an all-in-one smart-light development kit, which is developed based on
The development kit contains a number of ESP32-MeshKit-Lights and an ESP32-MeshKit-Sense board. ESP-
Mesh is developed upon ESP-MDF, Espressif Mesh Development Framework.
ESP32-MeshKit-Lights are smart lights besed on ESP-Mesh. Users can control the lights either with the
app, or the ESP32-MeshKit-Sense board that automatically switches on/off the lights by sensing the surrounding
temperature. ESP32-MeshKit-Lights also supports secondary development.
Figure 28 shows an ESP32-MeshKit-Light.
ESP32-MeshKit-Sense is a development board with an ESP32 module at its core. It integrates a temperature and
humidity sensor and an ambient light sensor. The board can be connected to display screens. The integrated
sensors on the board can automatically switch on/off the ESP32-MeshKit-Lights by sensing the surrounding en-
vironment. Apart from smart lights, the development board can also form a mesh network with other devices.
In addition, the ESP32-MeshKit-Sense development board is a low-power sensing solution that can be used to
detect the current consumption of ESP32 modules in a normal operation state or in sleep mode, when connected
to different peripherals.
Figure 29 shows an ESP32-MeshKit-Sense development board.
Espressif Systems
Figure 28: ESP32-MeshKit-Light
Figure 29: ESP32-MeshKit-Sense Development Board
23 ESP32 Hardware Design Guidelines V2.7
ESP-Mesh technology.
ESP-Mesh
