F19.33 Reserved
F19.34 Reserved
F19.35 Fault indication and
clock during the period
of recovery
F19.36 Continuous run
frequency selection
when alarm
F19.37 Abnormal standby
frequency
F19.38 Encoder disconnection
detection time
F19.39 Over speed （OS）
detection time
F19.40 Over speed （OS）
detection time
F19.41 Detection value when
speed deviation is too
large
F19.42 Detection time when
speed deviation is too
large
F19.43 Overvoltage suppression
coefficient
F19.44 Reserved
Function
Name
code
F20.00 Virtual input VDI1 function
selection
F20.01 Virtual input VDI2 function
selection
F20.02 Virtual input VDI3 function
selection
Tens digit: E
selection
0:alarm, continue run
1:alarm, stop run as halt mode
2:fault, free halt
Hundreds digit: contactor abnormal action
0:alarm，continue run
1:alarm，stop run as halt mode
2:fault，free halt
Thousands digit: running lack-Voltage fault
display action selection.
0:no detection
1:fault，free halt
Units digit: fault indication selection during the
period of fault reset automatically
0:action
1:no action
Tens digit: fault clock function selection: to
achieve fault display before power down: etc.
0:forbid
1:open
Match up with protect action
0:run at the frequency setup by now
1:run at the frequency of upper limit
2:run at the frequency of low limit
3:run at the frequency of abnormal for standby
0.00Hz～upper limit frequency
0.0～8.0s(No detection when value is 0)
0.0～120.0%(equals upper limit frequency)
0.00～20.00s（No detection when value is 0）
0.0～50.0%(equals upper limit frequency)
0.00～20.00s（No detection when value is 0）
0.0～100.0%
F20－Internal Virtual Input Output Node Parameter Group
0～90
0～90
0～90
6 Function parameter schedule graph
2
PROM abnormal action
Set Range
1 00 ×
1 0 ×
0.01Hz 10.00Hz ×
0.1s 0.0s ○
0.1% 120.0% ○
0.01s 0.00s ○
0.1% 10.0% ○
0.01s 0.00s ○
0.1% 90.0% ○
Min. Factory Modifi
Unit Default -cation
1 0 ○
1 0 ○
1 0 ○
