SHENZHEN ENCOM ELECTRIC TECHNOLOGIES CO. EN500 Series Service Manual page 136

Corresponding physical
F06.10 quantity of curve 2
inflexion setting
F06.11 Curve 2 Max. setting
Corresponding physical
F06.12 quantity of curve 2
Max. setting
F06.13 Curve 3 min. setting
Corresponding physical
F06.14 quantity of curve 3 min.
setting
Curve 3 inflexion 1
F06.15
setting
Corresponding physical
F06.16 quantity of curve 3
inflexion 1 setting
Curve 3 inflexion 2
F06.17
setting
Corresponding physical
F06.18 quantity of curve 3
inflexion 2 setting
F06.19 Curve 3 Max. setting
Corresponding physical
F06.20 quantity of curve 3
Max. setting
Take curve 1 as an example:
Parameter F06.01 ~ F06.06 is used to set analog quantity input voltage and its
representative set value relationship. When analog quantity input voltage is
greater than the set "Max. input"(F06.05), analog quantity voltage is calculated
based on "Max. input"; similarly, When analog input voltage is smaller than the
set "min. input "(F06.01), Set based on " curve lower than min. input setting
selection"(F06.21), calculated by min. input or 0.0%.
7 Detailed function specification
Range: 0.0 ~ 100.0%
Range: curve 2 inflexion
setting ~ 100.0%
Range: 0.0 ~ 100.0%
Range: 0.0% ~ curve 3
inflexion 1 setting
Range: 0.0 ~ 100.0%
Range: curve 3 min. setting ~
curve 3 inflexion 2 setting
Range: 0.0 ~ 100.0%
Range: curve 3 inflexion 1
setting ~ curve 3 Max. setting
Range: 0.0 ~ 100.0%
Range: curve 3 inflexion 1
setting ~100.0%
Range: 0.0 ~ 100.0%
50.0%
100.0%
100.0%
0.0%
0.0%
30.0%
30.0%
60.0%
60.0%
100.0%
100.0%
129
