digital setup
F01.02 Main frequency
digital control
F01.03 Auxiliary
frequency input
channel select
F01.04 Auxiliary
frequency digital
setup
F01.05 Auxiliary
frequency digital
control
F01.06 Main and
auxiliary provide
calculating setup
F01.07 Auxiliary
frequency provide
coefficient
F01.08 Coefficient after
complex of main
and auxiliary
frequency
F01.09 Auxiliary
frequency range
Only when parameter F01.00=0:3:4 valid.
Units digit: power down reserve setup
0:Main frequency power down reserve.
1:Main frequency power down no reserve.
Tens digit: halt reserve setup
0:Halt main frequency hold
1:Halt main frequency recovery F01.01
0: Operation keyboard digital setup
1: AI1 analog setup
2: AI2 analog setup
3:Terminal UP/DOWN adjusting setup
4:Communication provide.
5:EAI1 analog setup.
6:EAI2 analog setup
7:High speed pulse setup X8 terminal need choose the
suitable function)
8:Terminal pulse setup(X8 terminal need choose the
suitable function)
9:Terminal encoder setup(X1:X2 connect the encoder
punctuation input)
10～20: Reserved
0.00Hz～upper limit frequency
Units digit: power down reserve setup
0:Auxiliary frequency power down reserve.
1:Auxiliary frequency power down no reserve.
Tens digit: halt reserve setup
0:Halt auxiliary frequency hold.
1:Halt auxiliary frequency recovery parameter F01.04
0:Main frequency (complex frequency of current is
main frequency).
1: Auxiliary frequency(complex frequency of current
is auxiliary frequency.)
2: Plus(polarity oppose of complex and main
frequency，complex frequency is zero).
3:Minus(polarity oppose of complex and auxiliary
frequency，complex frequency is zero).
4:Multiplication(polarity opposed of main and
auxiliary frequency: complex frequency is zero).
5:Max(the max frequency of main and auxiliary
absolute value).
6:Min(the min frequency of main and auxiliary
absolute value).
7:Selection no-zero value(auxiliary is not negative，
main frequency prior；auxiliary is negative，complex
frequency is zero).
0.00～10.00
0.00～10.00
0:Relative upper limit frequency.
1:Relative main frequency.
6 Function parameter schedule graph
1
1
0.01Hz
1
1
0.01
0.01
1
00 ○
20 ○
0.00Hz ○
11 ○
0 ○
1.00 ○
1.00 ○
0 ○
