SHENZHEN ENCOM ELECTRIC TECHNOLOGIES CO. EN500 Series Service Manual page 172

F10.13 Step 13 setting
F10.14 Step 14 setting
F10.15 Step 15 setting
F10.01～F10.15 are used to configure the operating frequency, direction and
Acc/Dec time of each PLC operating step. These functions are all selected by
digits on different place of parameters. Details as below:
Unit digit: Frequency setting
0:select multi-frequency i. i=1～15,please refer to F10.31～F10.45 for
definitions of multi-frequency.
1:the frequency is determined by the combination of the main frequency
and the auxiliary frequency.
2: Reserved.
Tens digit: Direction choosing
0: Forward.
1: Reversed.
2: Determined by operating commands (FWD, REV)
Hundreds digit: Acc/Dec time choose
0: Acc/Dec time 1
1: Acc/Dec time 2
2: Acc/Dec time 3
3: Acc/Dec time 4
4: Acc/Dec time 5
5: Acc/Dec time 6
6: Acc/Dec time 7
7: Acc/Dec time 8
8: Acc/Dec time 9
9: Acc/Dec time 10
A: Acc/Dec time 11
B: Acc/Dec time 12
C: Acc/Dec time 13
D: Acc/Dec time 14
E: Acc/Dec time 15
Accelerate time1～15 defined by F01.17,F01.18,F04.16～F04.43
F10.16 Step 1 running time
F10.17 Step 2 running time
F10.18 Step 3 running time
Range: 000H～E22H
Range: 000H～E22H
Range: 000H～E22H
Range: 0～6000.0
Range: 0～6000.0
Range: 0～6000.0
7 Detailed function specification
000
000
000
10.0
10.0
10.0
165
