Obtaining documentation You can access the most up-to-date H3C product documentation on the World Wide Web at http://www.h3c.com. Click the links on the top navigation bar to obtain different categories of product documentation: [Technical Support & Documents > Technical Documents] –...
NOTE: The interface cards described in this document are applicable to multiple models of H3C switches, and the switch models that it applies to may update with time. For the latest information, consult H3C marketing staff or technical support.
Figure 2 LSW1XGT2P0 front panel (1) 1/10GBase-T (2) 1/10GBase-T autosensing autosensing Ethernet port Ethernet port LED 1/10GBase-T autosensing Ethernet port description Table 1 1/10GBase-T autosensing Ethernet port specifications Item Specification Connector type RJ-45 10 Gbps, full duplex • Port standard 1 Gbps, full duplex •...
IEEE 802.3an and 802.3ab standard LED description Every LSW1XGT4P0 and LSW1XGT2P0 interface card provides a port status LED for each port on the panel. It indicates the operating status of a port together with the port mode LED on the switch.
Page 8
Port mode Port status LED LED on the on the interface Description switch card The port is operating at a rate of 1 Gbps only. The LED is fast flashing Steady yellow when data is being sent and/or received on the port. Flashing yellow Power-on self test (POST) has (3 Hz)
Installing and removing an interface card This section takes the LSW1XGT4P0 interface card and the H3C S5820X-28C switch to illustrate the installation and removal procedures. The methods for installing and removing the LSW1XGT2P0 are similar. The following tools are needed for installation and removal: Phillips screwdriver •...
Page 10
Use a Phillips screwdriver to loosen the mounting screws of the filler panel on the expansion slot of the switch's front panel and remove the filler panel, as shown in Figure Keep the removed filler panel properly for future use. Figure 3 Removing a filler panel (1) Phillips screwdriver (2) Switch's front panel...
Page 11
Figure 4 Interface card appearance (1) Captive screw (2) Ejector lever Gently push the interface card in along the guide rails until the interface card is in close contact with the switch. (See callout 1 Figure 5.) Then push the ejector levers at both sides inward. (See callout 2 in Figure Fasten the captive screws with a Phillips screwdriver to secure the...
Figure 5 Installing an interface card NOTE: When tightening the captive screws at both sides of the interface card with a screwdriver or an electric screwdriver, make sure the torque is not bigger than 0.4 N-m. Removing an interface card Put on an ESD-preventive wrist strap and make sure the strap is in good contact with your skin and is properly grounded.
