H3C LSQM1QGS8A0 User Manual

H3C LSQM1QGS8A0 interface card
user manual-6PW102

▌Introduction

Overview
The LSQM1QGS8A0 interface card provides eight QSFP+ ports.
Figure 1 LSQM1QGS8A0 interface card front panel
(1) QSFP+ port LED
NOTE:
The LSQM1QGS8A0 interface card is currently applicable only to
H3C S7502E-XS and S7504E-XS switches. The applicable
switch models might change over time. For the most recent list of
applicable switch models, contact H3C Support or marketing
staff.

QSFP+ ports

You can install QSFP+ transceiver modules in
QSFP+ DAC cables in
4, and QSFP+ optical cables in
LSQM1QGS8A0 interface card.
(2) QSFP+ port
Table 3, QSFP+ to SFP+ DAC cables in
Table 5
1
Table 1
in the QSFP+ ports on the
and Table 2,
Table
