Ford Taurus Manual page 413

7. Remove the retainer and the fan from the motor shaft and unbolt the fan motor
from the shroud.
8. Installation is the reverse of the removal procedures. Tighten the fan shroud
retaining bolt to 23-33 inch lbs. (2.6-3.7 Nm). Tighten the fan shroud retaining nut
to 71-106 inch lbs. (8-12 Nm).
file://C:\DOCUME~1\SILENT~1\LOCALS~1\Temp\trsHIPBC.htm
Unbolt the fan assembly from the radiator
Remove the fan from the engine
